Technical Parameters Parameter Value Notes Displacement 90 cm³/rev 5.49 in³/rev Maximum Operating Pressure 420 bar 6,090 psi (continuous) Rated Pressure 350 bar 5,075 psi Peak Pressure 450 bar 6,525 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 600 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions DF Control Characteristics Electro-Hydraulic Proportional: Precise electronic control of pump displacement Pressure Compensation: Automatic pressure control capability Flow Control: Proportional flow regulation Load Sensing: Optional system optimization Multiple Control Modes: Pressure, flow, power control Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Electrical Control Specifications Parameter Specification Control Signal 0-10V DC or 4-20mA Supply Voltage 24V DC ±10% Current Consumption 1.5A maximum Response Time < 30 ms Hysteresis < 1.5% Protection Rating IP65 Rotation Right-hand (clockwise) Weight Approx. 38 kg (83.8 lb) Length ~285 mm (11.2 in) Width ~220 mm (8.7 in)

Technical Parameters Parameter Value Notes Displacement 74 cm³/rev 4.52 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 700 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Mechanical Efficiency ≥ 94% At rated conditions

Technical Parameters Parameter Value Notes Maximum Operating Pressure 25 bar 362 psi (standard) Burst Pressure 75 bar 1,088 psi Rated Flow Capacity 75 L/min 19.8 US gpm Port Size 1-1/2" SAE Straight thread O-ring Filter Rating 10 micron Absolute (β₁₀≥75) Bypass Setting 2.1 bar 30 psi (±0.35 bar) Element Material Glass fiber Composite media Housing Material Steel Powder coated

Technical Parameters Parameter Value Notes Displacement 57 cm³/rev 3.48 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 800 rpm For proper lubrication Volumetric Efficiency ≥ 95% At rated conditions Overall Efficiency ≥ 90% At rated conditions Mechanical Efficiency ≥ 93% At rated conditions Available Control Options Pressure Compensation (Standard) Load Sensing (LS) Pressure-Flow Compensation (QIC) Electro-Proportional Controls Hydraulic Remote Controls Torque Limiting Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 3/4" (No. 8) Rotation Right-hand (standard) Weight Approx. 22 kg (48.5 lb) Length ~245 mm (9.6 in) Width ~185 mm (7.3 in) Performance Data Parameter Value Theoretical Flow at 1800 rpm 102.6 L/min (27.1 US gpm) Actual Flow at 1800 rpm ≈ 97.5 L/min (25.8 US gpm) Input Power at 250 bar 42.8 kW (57.4 hp) Input Power at 280 bar 47.9 kW (64.2 hp) Noise Level < 74 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Standard Control Ranges Parameter Adjustment Range Pressure Setting 50-250 bar Flow Setting 0-100% of maximum flow Response Time < 60 ms typical Hysteresis < 3%

Technical Parameters Parameter Value Notes Displacement 141 cm³/rev 8.61 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Mechanical Efficiency ≥ 95% At rated conditions Available Control Options Pressure Compensation (Standard) Load Sensing (LS) Pressure-Flow Compensation (QIC) Electro-Proportional Controls Hydraulic Remote Controls Torque Limiting Power Control Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (standard) Weight Approx. 48 kg (106 lb) Length ~325 mm (12.8 in) Width ~235 mm (9.3 in)

Technical Parameters Parameter Value Notes Displacement 131 cm³/rev 7.99 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Mechanical Efficiency ≥ 95% At rated conditions Available Control Options Pressure Compensation (Standard) Load Sensing (LS) Pressure-Flow Compensation (QIC) Electro-Proportional Controls Hydraulic Remote Controls Torque Limiting Physical Specifications Parameter Specification Shaft Type SAE Standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (standard) Weight Approx. 42 kg (92.6 lb) Length ~298 mm (11.7 in) Width ~215 mm (8.5 in) Performance Data Parameter Value Theoretical Flow at 1800 rpm 235.8 L/min (62.3 US gpm) Actual Flow at 1800 rpm ≈ 226 L/min (59.7 US gpm) Input Power at 250 bar 98 kW (131 hp) Input Power at 280 bar 110 kW (147 hp) Noise Level < 78 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Standard Control Ranges Parameter Adjustment Range Pressure Setting 50-250 bar Flow Setting 0-100% of maximum flow Response Time < 45 ms typical Hysteresis < 3%

Technical Parameters Parameter Value Notes Displacement 98 cm³/rev 5.98 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 600 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Available Control Options Pressure Compensator (Standard) Load Sensing (Optional) Pressure-Flow Compensator (QIC) Electro-Proportional Controls (Various) Hydraulic Remote Controls Physical Specifications Parameter Specification Shaft Type Standard SAE Mounting SAE 2-bolt type "C" Port Size SAE No. 10 Rotation Right-hand (standard) Weight Approx. 32 kg (70.5 lb) Performance Data Parameter Value Theoretical Flow at 1800 rpm 176.4 L/min (46.6 US gpm) Actual Flow at 1800 rpm ≈ 169 L/min (44.6 US gpm) Input Power at 250 bar 73.5 kW (98.6 hp) Noise Level < 76 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s

Technical Parameters Parameter Value Notes Displacement 141 cm³/rev 8.61 in³/rev Maximum Operating Pressure 350 bar 5,075 psi (continuous) Peak Pressure 400 bar 5,800 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 500 rpm For proper lubrication Volumetric Efficiency ≥ 97% At rated conditions Overall Efficiency ≥ 92% At rated conditions Physical Specifications Parameter Specification Shaft Type SAE "C" standard Mounting SAE 2-bolt type "C" Port Size SAE 1-1/4" (No. 12) Rotation Right-hand (clockwise) Weight Approx. 48 kg (106 lb) Performance Data Parameter Value Theoretical Flow at 1800 rpm 254 L/min (67.1 US gpm) Actual Flow at 1800 rpm ≈ 246 L/min (65.0 US gpm) Input Power at 350 bar 150 kW (201 hp) Noise Level < 80 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Control Specifications Parameter Range Pressure Adjustment 70-350 bar Flow Adjustment 0-100% of maximum Response Time < 40 ms

Technical Parameters Parameter Value Notes Displacement 98 cm³/rev 5.98 in³/rev Maximum Operating Pressure 250 bar 3,625 psi (continuous) Peak Pressure 280 bar 4,060 psi (intermittent) Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Minimum Speed 600 rpm For proper lubrication Volumetric Efficiency ≥ 96% At rated conditions Overall Efficiency ≥ 91% At rated conditions Physical Specifications Parameter Specification Shaft Type Standard SAE Mounting SAE 2-bolt type "C" Port Size SAE No. 10 Rotation Right-hand (standard) Weight Approx. 32 kg (70.5 lb) Performance Data Parameter Value Theoretical Flow at 1800 rpm 176.4 L/min (46.6 US gpm) Actual Flow at 1800 rpm ≈ 169 L/min (44.6 US gpm) Input Power at 250 bar 73.5 kW (98.6 hp) Noise Level < 76 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s Control Adjustments Parameter Adjustment Range Pressure Setting 50-250 bar Flow Setting 0-100% of maximum flow Response Time < 50 ms typical

Technical Parameters Parameter Value Notes Displacement 74 cm³/rev 4.52 in³/rev Maximum Pressure 250 bar 3,625 psi continuous Peak Pressure 280 bar 4,060 psi intermittent Rated Speed 1800 rpm Recommended operating speed Maximum Speed 2400 rpm Absolute maximum Volumetric Efficiency ≥ 95% At rated conditions Overall Efficiency ≥ 90% At rated conditions Physical Specifications Parameter Specification Shaft Type Standard SAE Mounting SAE 2-bolt type "C" Port Size SAE No. 10 Rotation Right-hand (clockwise) Weight Approx. 35 kg (77 lb) Performance Data Parameter Value Flow at 1800 rpm 133 L/min (35 US gpm) Input Power at 250 bar 55 kW (74 hp) Noise Level < 78 dBA at 1 meter Minimum Viscosity 10 mm²/s Maximum Viscosity 160 mm²/s
