Key Features:
✔ Input: 100-240V AC (85-305V AC wide range)
✔ Output: 24V DC, 16A (20A peak for 5s)
✔ Efficiency: 94% (230V AC)
✔ Protections: Overcurrent/overvoltage/short-circuit/thermal
✔ Cooling: Smart temperature-controlled fan
✔ Parallel Operation: Supports up to 3 units
✔ Certifications: UL 508, CE, cULus, RoHS

Applications:

PLC & control systems

Industrial machinery

Robotics & automation

Process control

Mounting: DIN rail (35mm) or panel mount
Warranty: 5 years

Key Features
Input Voltage: 100-240V AC (50/60Hz) or 110-370V DC (wide-range)

Output: 24V DC (±1% regulation), 10A (240W continuous)

Efficiency: ≥93% (typical)

Protections:

Overload / Short-circuit (auto-recovery)

Overvoltage (≤35V DC clamp)

Thermal shutdown

Cooling: Natural convection (fanless design)

MTBF: >300,000 hours @ 40°C

Certifications & Compliance
Safety: UL 508, EN 62368-1

EMC: EN 61000-6-2/4

Industrial Standards: CE, RoHS

Applications
✔ Control cabinets
✔ Machine automation
✔ Robotics
✔ Process instrumentation

Key Features
Processor: 32-bit ARM Cortex-M7 (or equivalent industrial-grade MCU)

Memory: 64MB Flash / 16MB RAM (expandable via microSD)

I/O Configuration:

Digital Inputs: 8x 24V DC (sink/source)

Digital Outputs: 8x relay (5A @ 250V AC)

Analog Inputs: 4x 0-10V/4-20mA (16-bit ADC)

Communication Interfaces:

Ethernet: 10/100 Mbps (Modbus TCP, PROFINET optional)

Serial: RS-485 (Modbus RTU)

CANopen: For industrial fieldbus integration

Real-Time Clock (RTC): Battery-backed for event logging

Operating Voltage: 24V DC (±10%)

Environmental & Certifications
Operating Temp: -20°C to +60°C

Protection: IP40 (front panel) / IP20 (terminals)

Certifications: CE, UL 61010-1, RoHS

Applications
✔ Machine control
✔ Process automation
✔ Remote monitoring (SCADA)
✔ Energy management

Key Specifications
Inputs:

6x digital/analog (24V DC or 0-10V/4-20mA configurable)

Outputs:

6x relay/transistor (2A @ 230V AC / 24V DC)

Configurable Channels: 3x universal (I/O selectable)

Isolation: 1500V AC (channel-to-logic)

Protocol Support: Modbus RTU (via "C" suffix interface)

Typical Applications
PLC I/O expansion

Machine control systems

Sensor/actuator interfacing

Environmental Ratings
Operating Temp: -25°C to +55°C

Protection: IP20 (IP65 with enclosure)

Ordering Notes
"C" suffix indicates communication option (e.g., RS-485).

Eaton XNE Analog input card XI/ON ECO, 24 V DC, 8AI(voltage, current)/4(PT, ni, R)

Key Features
8 isolated digital inputs (sink/source configurable)

Input voltage: 24V DC (12-30V range)

Logic thresholds:

"1" signal: ≥15V DC

"0" signal: ≤5V DC

Input type: Dry contact (mechanical relay) or wet contact (PLC/PNP)

Isolation: 500V (channel-to-channel & field-to-logic)

Filtering: Programmable debounce (1ms to 100ms)

Status indicators: Per-channel LEDs (input state)

Mounting: DIN rail (35mm)

Applications
✔ PLC & DCS systems
✔ Machine automation
✔ Process control monitoring
✔ Safety interlocks

Certifications & Compliance
CE, RoHS, UL (if applicable)

EMC: EN 61000-6-2/4 (industrial immunity/emission)

Protection class: IP20 (enclosure-dependent)

Ordering Info
Model: XNE-8DI-24VDC-P

Connector type: Removable screw terminal

Operating temp: -25°C to +60°C

Description:
The XNE-GEBR-CANOPEN is a rugged industrial communication gateway module designed for seamless CANopen protocol integration in automation systems. This DIN-rail mounted interface device enables reliable data exchange between CANopen networks and industrial control equipment.

Key Features:

Protocol Support: CANopen DS301/DS302 compliant

Interface: Isolated CAN bus (ISO 11898-2)

Baud Rate: Configurable 10kbps-1Mbps

Connection: Screw terminal or D-sub connector

Isolation Voltage: 500V DC (min)

LED Indicators: Power, status, network activity

Mounting: Standard 35mm DIN rail

Operating Voltage: 24V DC (±15%)

Typical Applications:

Industrial machinery control systems

PLC network expansion

Motion control networks

Building automation

Automotive test systems

Certifications:

CE, RoHS compliant

Industrial EMC standards: EN 61000-6-2/4

Key Features:

Capacity: 50kVA/45kW

Topology: VFI (Voltage and Frequency Independent)

Runtime: Configurable with EBM (External Battery Module)

Efficiency: 94% (ECOnversion mode)

Standards: IEC 62040-3, UL 1778

Key Features:

Tripping Current (IΔn): 30mA (fixed)

Breaking Capacity: 6kA

Mechanical Life: 20,000 cycles

Terminals: Screw-type (up to 25mm² wire)

Standards: IEC 61008-1, CE

Eaton 9SX1000 - Uninterruptible Power Supply (UPS) - Brief Description
Key Features:
Capacity: 1000VA/900W (Line-Interactive)

Input Voltage: 100-120V AC (Single Phase)

Output Voltage: Pure Sine Wave (120V ±5%)

Battery: Sealed Lead-Acid (SLA), Hot-Swappable

Runtime: Variable (Depends on load; expandable with extra battery packs)

Efficiency: >95% (High-Efficiency Mode)

Transfer Time: <10ms (Automatic Voltage Regulation - AVR)

Display: LCD Panel (Status, load, battery level)

Protection: Surge, overload, short-circuit, deep discharge

Communication: USB/Serial (Eaton Intelligent Power Software)

Applications:
Critical IT equipment (PCs, servers, networking devices)

Home office & small business backup power

Point-of-sale (POS) systems & medical devices

Certifications: UL, CE, FCC, RoHS
