The ABB TINT4331 Inverter Power Board is an advanced control module designed for industrial applications, offering precise control over motor speed and direction, enhanced efficiency, and robust performance in demanding environments.

General Specifications Model: DG4V-3-2N-M-U-H7-60 Valve Type: Solenoid-operated directional control valve Mounting Pattern: CETOP 3 / NG6 / NFPA D03 Spool Type: 2N (directional flow pattern) Actuation: Wet-armature solenoid Centers: Spring-centered (M) Hydraulic Specifications Maximum Operating Pressure: Ports P, A, B: up to 350 bar (5075 psi) Port T: typically 160 bar (2320 psi), depending on spool and body Rated Flow: Up to 60 L/min (16 gpm) Hydraulic Fluid: Mineral-based hydraulic oils Fluid Viscosity Range: 15–400 cSt Recommended Operating Viscosity: 25–36 cSt Filtration: ISO 4406 18/16/13 or better Electrical Specifications Coil Designation: U-coil (Universal AC) Voltage Rating: Typically 110–120 VAC, 60 Hz (per H7-60 specification) Power Consumption: Approx. 30–40 VA (typical for DG4V coils) Connector Type: DIN 43650 Type-C (H7) Insulation Class: Class H (180°C) Environmental / Physical Mounting Position: Any orientation Temperature Range: –20°C to +70°C (fluid & ambient dependent) Weight: Approx. 1.5–2.0 kg Material: Hardened steel spool, cast body

Parameter Specification Product Model NZM2-XSH-12-84-NA Product Line Eaton NZM MCCB Frame Size NZM2 Rated Current (In) 125 A (Set by the "12" rating plug) Number of Poles 3 Rated Operational Voltage (Ue) 600 V AC Trip Unit Type Electronic (XSH) Protection Functions

• L - Long-Time (Overload)
• S - Short-Time (Short-Circuit)
• I - Instantaneous
• G - Ground Fault

All are adjustable. Rated Breaking Capacity (Icu) High (e.g., 65 kA @ 480V AC or similar). Must be verified from datasheet. Communication Capability Yes, typically ready for communication modules (e.g., for Modbus, PROFIBUS). Mounting Fixed or Plug-in (specific type to be confirmed) Standards Compliance UL 489, CSA C22.2 No. 5 (for the NA market)
