Parameter Specification Model 39A9228X012 Product Line Fisher Type 678C Device Type Self-Relieving Supply Pressure Regulator Supply Pressure Range Up to 300 psig (20.7 bar) Output Pressure Range 3 to 65 psig (0.2 to 4.5 bar) Adjustable via the spring knob. Relieving Capacity Up to 25 scfm (0.71 Nm³/min) Capacity to vent excess downstream pressure. Connection Size 1/4 in. NPT (F) for Supply, Output, and Gauge Ports Mounting Panel Mount (Requires a 1-1/8 inch or 29mm diameter hole) Housing Material Zinc-Aluminum Alloy (ZA-12) Internal Parts Brass, Buna-N, Stainless Steel, Anodized Aluminum Standard Color Gray Temperature Range -20° to 180°F (-29° to 82°C)

Parameter Specification Model 26A5291X012 Product Line Fisher 667 / 667FP Actuator Component Type Spring Cartridge (Spring Module) Actuator Size Size 70 Spring Range 1440 - 2240 psi (on a 667 diaphragm) Equivalent Force: Approx. 3620 - 5620 lbf (16.1 - 25.0 kN) Action Provides the return force for spring-return actuators. The fail-safe direction (FO or FC) is determined by how the actuator is oriented on the valve. Fail-Safe Action Enables Fail-Closed or Fail-Open operation upon air supply failure. Standard Style Standard (Non-Fire Safe) Material Carbon Steel Spring; Protective Epoxy Coating

Parameter Specification Notes / Details Model 16A5376X082 Product Line Fisher 1052 NAMUR Pneumatic Actuator Actuator Type Double-Acting (Springless) Requires air for both open & close strokes. Action Double-Acting Fail-Safe Mode None (Air-to-Air) Lacks a spring. Stays in last position on air failure unless paired with an external safety system. Torque Output Approx. 413 lb-in (47 Nm) at 80 psi (5.5 bar) supply pressure. Torque is proportional to air supply pressure. Supply Pressure Range 40 to 120 psi (2.8 to 8.3 bar) Standard operating range. Standard Air Connection NPT 1/4" Mounting Standard VDI/VDE 3845 (NAMUR) Standardized interface for quarter-turn valve accessories (e.g., limit switches, solenoid valves). Mounting Style Direct to NAMUR-compliant valves; Side-mounted to Fisher 1061/1066 piston actuators for double-block-and-bleed applications. Temperature Range Standard: -4° to 180°F (-20° to 82°C) Low Temp.: -40° to 180°F (-40° to 82°C) (with optional seals) Materials Body: Die-cast aluminum Corrosion Protection: Powder-coated epoxy finish Internal Parts: Plated for corrosion resistance.

Parameter Specification Model DVC6200 SIS Product Line Fisher FIELDVUE® Type Digital Valve Controller / Positioner Certification SIL 2 capable per IEC 61508/61511 (hardware fault tolerance 0 with SFF > 90%). SIL 3 capable for specific architectures (e.g., HFT 1). Certified by exida. Input Signal 4-20 mA with HART® 7 protocol; Digital (via FOUNDATION™ fieldbus H1 or PROFIBUS® PA available as options) Supply Pressure Up to 150 psi (10.3 bar) for single-acting; Up to 125 psi (8.6 bar) for double-acting Air Delivery Capacity High Capacity: Up to 110 scfm (187 Nm³/h) Standard Capacity: Up to 32 scfm (54 Nm³/h) Output Action Single-acting (for spring-return actuators) or Double-acting Fail-safe Action De-energize to trip. Upon loss of power or signal, it exhausts air from the actuator to drive the valve to its safe state. Pilot Valve Type Piezoelectric, low power consumption Operating Temperature Standard: -40° to 185°F (-40° to 85°C) Extended: -60° to 185°F (-51° to 85°C) with optional heater Enclosure Rating NEMA 4X, Type 4, IP66/67 Communication HART 7 (via 4-20 mA signal), Local Magnetic Communicator, and/or FIELDVUE DVC6200 SIS Setup Software Diagnostics Built-in Partial Stroke Test (PST), travel, pressure, and step response data collection, performance alerts. Materials Aluminum enclosure with epoxy paint; Stainless steel internal parts and fittings. Safety Manual Available and required for proper use in SIS loops.

Technical Parameters Parameter Value / Description Fisher Model Number 47B9380X022 Type Pilot-Operated Pressure Regulator (Pilot) Primary Function Acts as a control pilot for a main valve or as a standalone regulator. Pilot Supply Source Typically tapped from upstream pressure or an external gas supply. Body Material Aluminum Trim Materials Standard corrosion-resistant materials (e.g., stainless steel & elastomers). Pressure Rating Typically 1440 psig (100 bar) or similar high pressure. Outlet Pressure Range (P2) Determined by the internal spring. The "X022" suffix likely specifies a particular range. Common 47B series ranges: 5-250 psig, 20-500 psig, etc. Must be confirmed from order records. Inlet Pressure (P1) Up to the pressure rating (e.g., 1440 psig). Connections Typically 1/4" or 1/2" NPT Female Diaphragm Material Typically Nylon-coated fabric or Viton (FKM).

Technical Parameters Parameter Value / Description Fisher Model Number DVC6030 Product Line FIELDVUE Type Digital Valve Controller (Positioner) Action Single-Acting Input Signal 4-20 mA DC, with HART protocol digital communication Supply Pressure Up to 150 psig (10.3 bar) Output Pressure Up to supply pressure Air Consumption Typically < 0.15 SCFM (0.25 Nm³/hr) at steady state Accuracy Better than ±0.5% of span Dead Band Better than 0.05% of span Travel Range Configurable, typically supports 0.2 to 4.0 inches (5 to 100 mm) Ambient Temperature -40°F to +185°F (-40°C to +85°C) Enclosure Rating NEMA 4X (IP66) Communication HART 5/6/7 Mounting Linear (via mounting kit); can be adapted for some rotary valves

Technical Parameters Parameter Value / Description for 167DA-85 Fisher Model Number 167DA-85 Type Direct-Operated Pressure Reducing Regulator Orifice Size / Connection 1/2 inch Female NPT - This is the key identifier for the -85 suffix. Body Material Diecast Zinc Trim Materials Typically includes EPDM gaskets, Neoprene diaphragm, and reinforced elastomer valve head. Max Inlet Pressure (P1) 400 psig (28 bar) Outlet Pressure Range (P2) 5 to 125 psig (0.3 to 8.6 bar) - This is the most common spring range for this model. Temperature Range -20°F to +150°F (-29°C to +66°C) Flow Coefficient (Cv) Approximately 3.0 (varies with specific pressure drop)

Technical Parameters Parameter Value / Description Fisher Model Number 1V659905092 Type Pilot-Operated Pressure Reducing Regulator Valve Size (Pipe Size) 4 inch (4") Orifice Size Correlated to valve size (e.g., 4 inch) End Connections Flanged (Typically RF or RTJ) Pressure Rating (ANSI Class) Class 300 Body Material Carbon Steel (e.g., WCB) Trim Material Standard Trim (Typically 304 Stainless Steel) Diaphragm Material Typically Nitrile (Buna-N) for standard service. Max Inlet Pressure (P1) Up to 720 psig (50 bar) approximately (based on Class 300 rating). Outlet Pressure Range (P2) Determined by the spring range. Common examples: 20-125 psig, 50-250 psig, or other ranges. Must be confirmed from order records. Temperature Range Standard: -20°F to +150°F (-29°C to +66°C) with standard elastomers.

Technical Parameters Parameter Value / Description Fisher Model Number 1V711606242 Type Pilot-Operated Pressure Reducing Regulator Valve Size (Port Size) 2 inch (2") - Note: This is the port size, not necessarily the pipe size. Orifice Size Typically 2 inch (Depending on trim) End Connections Flanged (RF or RTJ are common) Pressure Rating (ANSI Class) Class 300 (or as specified) Body Material Carbon Steel (e.g., WCB) Trim Material Standard Trim (e.g., 304 Stainless Steel) Main Diaphragm Material Typically Nitrile (Buna-N) for standard service. Max Inlet Pressure (P1) Varies with body rating, e.g., up to 750 psig (51.7 bar) for Class 300. Outlet Pressure Range (P2) Depends on the installed spring range. Example Ranges: 3 to 9 psig, 8 to 30 psig, 20 to 60 psig, etc. Temperature Range Standard: -20°F to +150°F (-29°C to +66°C) with standard elastomers.

Technical Parameters Parameter Value / Description Fisher Model Number 1V711606242 Type Pilot-Operated Pressure Reducing Regulator Valve Size (Port Size) 2 inch (2") Orifice Size Typically 2 inch (Depending on trim) End Connections Flanged (RF or RTJ are common) Pressure Rating (ANSI Class) Class 300 (or as specified) Body Material Carbon Steel (e.g., WCB) Trim Material Standard Trim (e.g., 304 Stainless Steel) Main Diaphragm Material Typically Nitrile (Buna-N) or other elastomers for standard service. Pilot Diaphragm Material Typically Nitrile (Buna-N) Max Inlet Pressure (P1) Varies with body rating, e.g., up to 750 psig (51.7 bar) for Class 300. Outlet Pressure Range (P2) Depends on the specific spring range installed. Example Spring Ranges: 3 to 9 psig, 8 to 30 psig, 20 to 60 psig, etc. Temperature Range Standard: -20°F to +150°F (-29°C to +66°C) with standard elastomers. Higher temperatures with special materials. Pilot Connection Size 1/2 inch NPT Leakage Class Class IV (Metal-to-metal seat) or Class VI (Soft seat) depending on trim.
