Technical Specifications Parameter DN40 DN50 DN65 Nominal Diameter 40 50 65 Imperial Equivalent 1½ inch 2 inch 2½ inch Pipe Outer Diameter ≈ 48.3 mm (1.90 in) ≈ 60.3 mm (2.37 in) ≈ 76.1 mm (3.00 in) Flange Standards ISO 6162, ANSI B16.5 ISO 6162, ANSI B16.5 ISO 6162, ANSI B16.5 Typical Valve Types Control valves, Regulating valves, Ball valves Control valves, Regulating valves, Gate valves High-pressure control valves, Large-size regulating valves

Technical Specifications Parameter Specification Part Number FS-67CFR-362 Description Filter Regulator Mounting Kit Compatible Components Fisher 67CFR Series Actuator Pilots and related pneumatic systems Mounting Type Bolt-on bracket system Kit Contents • Precision mounting bracket • Stainless steel bolts and fasteners • Sealing gaskets • Pneumatic connecting fittings Bracket Material Galvanized carbon steel (standard) or stainless steel (optional) Hardware Material Stainless steel (for corrosion resistance) Surface Treatment Anti-corrosion coating Installation Tool-based assembly requiring standard wrenches

Technical Specifications Parameter Specification Nominal Diameter DN25 (1 inch) Pressure Class 150 LB (ANSI B16.5) Flange Type Raised Face (RF) - standard Max Working Pressure 285 psi @ 100°F (19.7 bar) Bolt Circle Diameter ≈ 3.25 inches (82.6 mm) - for 150LB RF flange Flange Thickness ≈ 0.56 inches (14.3 mm) - for 150LB RF flange Number of Bolts 4 - for 150LB DN25 flange Bolt Size 0.62 inch (15.7 mm) diameter

Technical Specifications Parameter Specification Valve Type Diaphragm Control Valve Inlet Size DN65 (2½ inch) Outlet Size DN50 (2 inch) Pressure Rating ANSI Class 150 or 300 (specific to order) Flow Characteristic Equal Percentage or Linear (trim dependent) Actuator Type Diaphragm Actuator Body Material Carbon Steel (WCB) or other specified materials Trim Material Stainless Steel (standard) Temperature Range -20°F to 400°F (-29°C to 204°C) - standard End Connections Flanged (RF facing standard)

Technical Specifications Parameter Specification Model DVP-2000 Type Digital Valve Positioner Input Signal 4-20 mA (2-wire) with HART protocol Output Signal Pneumatic pressure to actuator (3-15, 6-30 psi or other ranges) Supply Air Pressure 20-150 psig (1.4-10.3 bar) Air Consumption < 0.15 SCFM (4.2 NLPM) at steady state Accuracy ≤ 0.5% of span (including linearity, dead band, hysteresis) Travel Feedback Non-contact magnetic position sensing Enclosure Rating NEMA 4X (IP66/67) Ambient Temperature -40°F to 185°F (-40°C to 85°C) Mounting Direct mount to Fisher and other manufacturers' actuators Communication HART 5/7 protocol

Technical Specifications Parameter Specification Model KJ1501x1-BC1 Type Control Valve Assembly Valve Style Globe Valve (typical for KJ series) Valve Size Specific size encoded in "KJ1501x1" (e.g., 1.5 inch or similar) Pressure Class ANSI Class 150 or 300 (encoded in model number) Actuator Type Pneumatic Spring-Diaphragm ("BC1" configuration) Actuator Action Spring-Return (fail-safe) Air Signal 3-15 psig (0.2-1.0 bar) standard Flow Characteristic Equal Percentage or Linear (trim dependent) End Connections Flanged (RF facing standard) Temperature Range -20°F to 450°F (-29°C to 232°C) - standard

Technical Specifications Parameter Specification Part Number 159000677 Description Repair Kit or Component Assembly Kit Type Maintenance/Repair Kit for Fisher valves or actuators Contents Specific components vary (typically includes seals, gaskets, O-rings, fasteners) Compatibility Designed for specific Fisher valve or actuator models Materials Buna-N, PTFE, Stainless Steel, or other engineered materials Temperature Rating Dependent on component materials (typically -20°F to 400°F / -29°C to 204°C) Pressure Rating Matches original equipment specifications

Parameters / Specifications Model: 3‑9900.394 Direct Conductivity/Resistivity Module Compatible With: GF Signet 9900 transmitter platform Input Sensor Types: Conductivity and resistivity electrodes (e.g., Signet 2819 to 2823; Signet 2839 to 2842) Function: Converts electrode signals into conditioned output suitable for the 9900 transmitter; enables conductivity, resistivity, and salinity measurement via the 9900 digital inputs Weight: Approximately 0.2 lb (~0.09 kg) in one listing Dimensions: Approx. 4″ × 4″ × 4″ (~101 mm × 101 mm × 101 mm) in one listing Mounting/Format: Module card designed to slide into or attach to the 9900 transmitter enclosure Alternate Part Number: 159 001 699 (associated part number for this module) Application: Water quality monitoring, process analytics, inline conductivity/resistivity measurement in industries such as water treatment, food & beverage, semiconductor, aquaculture, marine, pulp & paper Key Features: Direct interface of conductivity/resistivity electrodes to transmitter Supports salinity measurement when combined with the 9900 digital S3L inputs Simplifies wiring and integration by using a dedicated module rather than separate transmitter for each sensor type

Parameter Specification / Description Model Series Fisher 655 Actuator Type Scotch-Yoke / Rack and Pinion Pneumatic Piston Actuator Configurations Double-Acting (Air-to-Air): Requires air to open and close. No fail-safe spring. Spring-Return: Provides fail-safe action (fail-open or fail-closed) upon air supply loss. Actuator Sizes 30, 40, 50, 60, 70, 80 (The number indicates the piston diameter in millimeters) Standard Supply Pressure 40 to 120 psi (2.8 to 8.3 bar) Temperature Range Standard: -4° to 180°F (-20° to 82°C) Low Temp.: -40°F (-40°C) with optional seals & lubrication Mounting Directly to ISO 5211 mounting pads and NAMUR (VDI/VDE 3845) compliant valves. Accessory Mounting NAMUR standard for easy attachment of solenoid valves, limit switches, and positioners. Body Material Standard: Aluminum with corrosion-resistant epoxy coating. Optional: Stainless Steel (e.g., for corrosive environments). Spring Material Carbon Steel Piston Seals Standard: Buna-N Optional: Ethylene Propylene (EPDM), Fluorocarbon (Viton)

Parameter Specification Model MR95H Product Line Fisher MR Series I/P Converter Device Type Current-to-Pressure (I/P) Converter Input Signal 4-20 mA DC (Standard two-wire) Output Pressure Range Standard: 3-15 psig (0.2-1.0 bar) Other Ranges: Available, such as 3-27 psig, 6-30 psig. Supply Pressure 20 psig (1.4 bar) minimum, 40 psig (2.8 bar) typical, up to 120 psig (8.3 bar) maximum. Must be at least 3-5 psi above the required output pressure. Air Consumption Static (No Signal): Typically ≤ 0.2 scfm (0.0057 Nm³/min) Dynamic (With Signal): Varies with output. Accuracy Typically ±0.5% of span (including linearity, hysteresis, and dead band) Supply Connection 1/4 in. NPT (F) Output Connection 1/4 in. NPT (F) Mounting Standard: Panel mount (for 1-1/8 in. or 29mm diameter hole) Optional: Manifold mount, surface mount, or 35mm DIN rail kit. Enclosure Rating NEMA 4X (IP66) when properly mounted. Material Aluminum enclosure with polyurethane coating. Ambient Temperature Range -20° to 180°F (-29° to 82°C)
