Parameter Specification Product Series Eaton IZM Model Number IZM65N4-A04WH Description Molded Case Circuit Breaker, 65A, 4-Pole, Fixed Mount Rated Current (Iu) 65 A Number of Poles 4 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Trip Unit Thermal-Magnetic (Fixed) Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton A22 (Accessory) Model Number A22-RD-53 Description 8-Pin Round Pin Relay Socket Terminal Type Screw Clamp Number of Pins 8 Pin Shape Round Rated Operational Current Typically 10A (dependent on the relay used) Rated Insulation Voltage 500V Mounting DIN Rail (35mm) Material Thermoplastic (PBT) Compatible Devices 8-pin round pin control relays, timer relays (e.g., Eaton A22 series compatible devices) Standards & Certifications UL 508, CSA, CE

Parameter Specification Product Series Eaton Power Xpert D2 Model Number PDC94G0100D2YJ Description DIN Rail DC Power Supply, 100W, 24V DC Out Output Power 100 W Output Voltage 24 V DC Output Current 4.2 A Input Voltage Range 85 - 264 V AC (Wide Range, suitable for global use) Input Frequency 47 - 63 Hz Efficiency High (typically >89%) Power Factor (PFC) >0.9 Line Regulation <±1% Load Regulation <±1% Ripple & Noise <150mV peak-to-peak Protections Overload (115-150%), Overvoltage, Short-circuit Operating Temperature -25°C to +70°C (with derating) Cooling Convection (Fanless) Mounting DIN Rail (35mm) Safety & EMC CE, cULus, RoHS, compliant with IEC/EN/UL 62368-1

Parameter Specification Product Series Eaton C22 Series Model Number C22-D-X-K10-P30 Description Electronic Pre-set Counter, 6-Digit, Dual Preset Supply Voltage 24-240V AC/DC (Wide Range) Counting Speed Up to 1kHz (depending on input type) Number of Digits 6 Number of Presets 2 (P1, P2) Outputs 2 relay outputs (for P1 and P2) Output Contact Rating Typically 3A @ 250V AC Input Types Depending on "K10" code (e.g., dry contact, NAMUR, voltage) Mounting DIN Rail (35mm) Display 6-digit LED or LCD Standards & Certifications CE, cULus

Parameter Specification Product Type Electronic Multi-Function Timer Relay Model Number T0-4-8222/IVS Supply Voltage 24-240V AC/DC (Wide Range) Timing Functions Multiple (e.g., On-delay, Off-delay, Interval, Flasher, One-shot) Number of Outputs 1 or 2 changeover (SPDT) relay outputs Output Contact Rating Typically 8A @ 250V AC Time Range Adjustable, typically from 0.05 seconds up to 300 hours (depending on function and model) Setting Method Via DIP-switches or a rotary switch to select functions and ranges Mounting DIN Rail (35mm) Terminals Screw Clamp or Spring Clamp (specific to /IVS variant) Status Indication LED for power and output status Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton DS6 Model Number DS6-340-22K-MX Description Soft Starter with Bypass, 340A Frame, 22kW, 400V Rated Supply Voltage 400V AC, 50/60 Hz (3 Phase) Frame Size 340A Motor Power Rating 22 kW (30 HP) @ 400V Set Current / Max. Current ~41-45A (估算，对应22kW电机) Control Supply Voltage 根据订货型号而定，常见100-250V AC或24V AC/DC Integrated Bypass Yes (Internal Bypass Contactor) Keypad Basic Keypad Start Control Voltage ramp, Current limit Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating Communication Enclosure Rating IP00

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+V36N3S Description Variable Frequency Drive, 68A, 37kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 68 A Motor Power Rating 37 kW (50 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+V42N3S Description Variable Frequency Drive, 81A, 45kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 81 A Motor Power Rating 45 kW (60 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+TN3S Description Micro Variable Frequency Drive Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current ~3 - 4 A Motor Power Rating ~0.75 - 1.5 kW (~1 - 2 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control Integrated Features EMC Filter (Standard), Basic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard) Enclosure Rating IP20 / UL Type Open Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton DS7 Model Number DS7-340SX041N0-N Description Soft Starter with Bypass, 340A Frame, 41A, 22kW, 400V Rated Supply Voltage 400V AC, 50/60 Hz (3 Phase) Frame Size 340A Set Current / Max. Current 41 A (Adjustable within the frame's range) Motor Power Rating 22 kW (30 HP) @ 400V Control Supply Voltage 100-250V AC (as set by "SX" code) Integrated Bypass Yes (Internal Bypass Contactor) Keypad Standard Keypad (Not the advanced LCD version) Start Control Voltage ramp, Current limit Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating Communication Optional communication modules (e.g., Profibus DP, DeviceNet, Modbus RTU) Enclosure Rating IP00 (Open Type, must be installed in a control panel) Standards & Certifications CE, cULus, RoHS
