Parameter Specification Product Series Eaton P5 Model Number P5-160/V/SVB Description Motor Protection Circuit Breaker, 160A Frame, Adjustable, 3-Pole Frame Size 160A Rated Operational Current (Iu) Adjustable within the frame range (e.g., 100A - 160A) Number of Poles 3 Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 790V AC Rated Short-circuit Breaking Capacity (Icu) High, e.g., 50 kA @ 400V AC (需查证具体目录) Overload Protection Setting (Ir) Adjustable (via a dial or switches) Short-Circuit Protection Setting (Im) Fixed or Adjustable (depending on model) Auxiliary Contacts Yes (as specified by "SVB" - typically includes signaling and control contacts) Mounting Fixed or Plug-in (depending on variant) Standards & Certifications IEC/EN 60947-2, IEC/EN 60947-4-1, UL 508, CE

Parameter Specification Product Series Eaton ELD6 (Electronic Accessory for D6 MCB) Model Number ELD6-63/4/C/03 Description Electronic Residual Current Release Module, for 4-Pole MCB, 63A, Curve C, 300mA Type A Compatible With Eaton D6 series, 4-pole, C-curve, up to 63A MCB Max. Rated Current of Assembly Up to 63 A Number of Poles 4 Poles (3 Phase + Neutral) Rated Residual Operating Current (IΔn) 300 mA Residual Current Type Type A (for alternating and pulsating direct currents) Technology Electronic (Requires auxiliary power from the monitored circuit to operate) Rated Voltage 400V AC (3P+N) Mounting Snaps onto the side of a compatible D6 MCB on a DIN Rail. Standards & Certifications IEC 61009-1, CE

Parameter Specification Product Series Eaton ZB Model Number ZB12C-4 Description Feed-through Terminal Block, 12mm, Gray Rated Voltage 400 V Rated Current 76 A Cross-Section (Wire Size) 16 mm² Number of Poles per Unit 1 Mounting DIN Rail (35mm), Snap-on Insulation Material Polyamide (PA) Clamping Material Tin-plated Copper Alloy Tightening Torque 2.0 Nm Standards & Certifications UL 1059, CSA 22.2, IEC 60947-7-1

Parameter Specification Product Series Eaton Power Xpert C3 Model Number PDC3-400A Description DIN Rail DC Power Supply, 400W, 24V DC Out Output Power 400 W Output Voltage 24 V DC Output Current 16.7 A Input Voltage Range 85 - 264 V AC (Wide Range, suitable for global use) Input Frequency 47 - 63 Hz Efficiency High (typically >90%) Power Factor (PFC) >0.95 Line Regulation <±1% Load Regulation <±1% Ripple & Noise <150mV peak-to-peak Protections Overload (105-150%), Overvoltage, Short-circuit, Over-temperature Operating Temperature -25°C to +70°C (with derating) Cooling Convection (Fanless) Mounting DIN Rail (35mm) Safety & EMC CE, cULus, RoHS, compliant with IEC/EN/UL 62368-1

Parameter Specification Product Series Eaton PKZ (PKM) Model Number PKM0-0.63 Description Thermal Overload Relay, 0.40-0.63A Motor Current Setting Range (FLA) 0.40 - 0.63 A Poles 3 (for 3-phase motor protection) Tripping Class 10 (Standard) Ambient Compensated Yes Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton PKZ (PKM) Model Number PKM0-1.6 Description Thermal Overload Relay, 1.0-1.6A Motor Current Setting Range (FLA) 1.0 - 1.6 A Poles 3 (for 3-phase motor protection) Tripping Class 10 (Standard) Ambient Compensated Yes Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton PKZ (PKM) Model Number PKM0-12 Description Thermal Overload Relay, 0.10-0.16A Motor Current Setting Range (FLA) 0.10 - 0.16 A Poles 3 (for 3-phase motor protection) Tripping Class 10 (Standard) Ambient Compensated Yes Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton PLHTX (Accessory for PLH/PLHT MCB) Model Number PLHTX-D100/4 Description Residual Current Release Module, for 4-Pole MCB, 100A Compatible With Eaton PLH/PLHT series, 4-pole, 100A Miniature Circuit Breaker Rated Current of Assembly 100 A Number of Poles 4 Poles (3 Phase + Neutral) Rated Residual Operating Current (IΔn) 30 mA Residual Current Type Type A (for alternating and pulsating direct currents) Rated Voltage 400V AC (3P+N) Mounting Snaps onto the side of a compatible PLH/PLHT MCB on a DIN Rail. Standards & Certifications IEC 61009-1, CE

Parameter Specification Product Series Eaton PLD101X (Accessory for PL10 MCB) Model Variants PLD101X-C10 (for 10A MCB), PLD101X-C40 (for 40A MCB) Description Residual Current Release Module, for 1P+N MCB, C-Curve Compatible With Eaton PL10 series, 2-pole (1P+N), C-Curve Miniature Circuit Breakers Rated Current of Assembly 10 A (for C10) / 40 A (for C40) Number of Poles 2 Poles (1 Phase + Neutral) Rated Residual Operating Current (IΔn) Typically 30 mA Residual Current Type Typically Type A Rated Voltage 230V AC (1P+N) Mounting Snaps onto the side of a compatible PL10 MCB on a DIN Rail. Standards & Certifications IEC 61009-1, CE

Parameter Specification Product Series Eaton PL9X (Accessory for PL9 MCB) Model Number PL9X-C32 Description Residual Current Release Module, for 1P+N (2-Pole) MCB, 32A Compatible With Eaton PL9 series, 2-pole (1P+N), 32A Miniature Circuit Breaker Rated Current of Assembly 32 A Number of Poles 2 Poles (1 Phase + Neutral) Rated Residual Operating Current (IΔn) Typically 30 mA Residual Current Type Typically Type A Rated Voltage 230V AC (1P+N) Mounting Snaps onto the side of a compatible PL9 MCB on a DIN Rail. Standards & Certifications IEC 61009-1, CE
