Core Specifications
1. ACS800-04-0135-3 Drive Unit

Output Power: 135kW (181HP) at 400V

Output Current: 260A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

200% for 3 seconds

Control Technology: Enhanced Direct Torque Control (DTC)

Efficiency: 98.3% at full load

Switching Frequency: 1-5kHz (adaptive)

2. D150 Braking Module

Continuous Braking Power: 135kW

Peak Braking Capacity: 270kW (10% duty cycle)

Response Time: <1ms

Protection: Thermal overload with auto-derating

3. E210 Encoder Interface

Supported Encoders: Absolute/Incremental

Resolution: Up to 24-bit

Protocols: EnDat 2.2, Hiperface DSL, SSI

Update Rate: 500kHz

4. P901 Control Panel

10.1" sunlight-readable multi-touch display

20-language interface with technical dictionary

Industrial-grade web server (IEC 62443 compliant)

64GB NVMe solid-state storage

Dual USB 3.2 Gen 2 ports

Integrated oscilloscope function

Key System Features
Performance Enhancements:
✔ Ultra-Precise Control: ±0.005% speed accuracy
✔ Adaptive Braking: AI-optimized deceleration profiles
✔ Process Intelligence: Quad PID controllers with cross-coupling
✔ Energy Optimization: Regenerative power management

Connectivity Suite:

Standard Interfaces:

2× 1Gbps Ethernet (PROFINET IRT, EtherNet/IP)

OPC UA Pub/Sub

IEC 61850 protocol support

Optional Modules:

PROFIBUS DP-V3

BACnet/SC

5G wireless communication

Safety Systems:

Certified Safety:

SIL3/PL e (STO, SS1, SLS, SBC)

ISO 13849-1 Cat.4/PLe

Protection Features:

Motor insulation monitoring

Bearing current protection

Adaptive thermal management

Physical Specifications
Enclosure Rating: IP21 (cabinet-mounted)

Cooling System: Hybrid liquid/forced air cooling

Dimensions: 500 × 1800 × 450mm (W×H×D)

Weight: 195kg (complete system)

Noise Level: <66dB(A) at 1m

Cooling Capacity: 3000W heat dissipation

Core Specifications
Drive Unit (ACS800-04P-0170-3):

Output Power: 170kW (228HP) at 400V

Output Current: 330A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 98.2% at full load

Switching Frequency: 1-4kHz (adaptive)

P901 Control Panel:

7" high-brightness industrial touchscreen

Multi-language interface (16 languages)

Integrated web server with remote diagnostics

32GB data logging capacity

USB 3.0 configuration ports (front/rear)

Real-time clock with battery backup

Key System Features
Performance Enhancements:
✔ Precision Control: ±0.02% speed accuracy
✔ Adaptive Programming: 12 application macros
✔ Process Optimization: Triple PID control
✔ Energy Management: kWh/MWh monitoring

Connectivity:

Standard Interfaces:

PROFINET IRT (2 ports)

EtherNet/IP

OPC UA

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Wireless LAN

Safety Systems:

SIL3/PL e certified safety functions

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Automatic self-diagnostics

Physical Specifications
Enclosure Rating: IP21 (cabinet-mounted)

Cooling System: Forced air with dust detection

Dimensions: 450 × 900 × 400mm (W×H×D)

Weight: 85kg

Noise Level: <68dB at 1m

Key Specifications
Parameter Specification
Output Current 157A
Rated Power 75kW (400V, 4-pole motor)
Input Voltage 3-phase 380-480V AC (±10%)
Overload 150% for 60 seconds
Control Method Sensorless Vector Control
Efficiency >97.5% at full load
Enclosure IP21 (open chassis)
Advanced Features
Performance Features:
✔ Adaptive Programming - Automatic motor adaptation
✔ Energy Optimization - Saves up to 50% energy in pump/fan apps
✔ PID Control - Built-in dual PID controllers
✔ Fast Response - <10ms torque response

Protection & Safety:

Motor thermal protection (I²t)

Short circuit/ground fault protection

Phase loss detection

Safe Torque Off (STO) option

Connectivity:

Standard Modbus RTU (RS485)

Optional fieldbus modules:

PROFIBUS DP

BACnet MS/TP

Ethernet/IP

Mechanical Specifications
Dimensions: 255 × 245 × 220mm (W×H×D)

Weight: 15kg

Cooling: Temperature-controlled fan

Ambient Temp: -10°C to +50°C

Humidity: 5-95% non-condensing

Core Specifications
Drive Module (ACS800-04M-0320-3):

Output Power: 320kW (430HP) at 400V

Output Current: 620A continuous

DC Link Voltage: 510-750V DC

Overload Capacity:

110% continuous

150% for 60 seconds

200% for 3 seconds

Control Technology: Enhanced DTC with AI optimization

Efficiency: 98.6% at full load

Switching Frequency: 1-4kHz (adaptive)

P901 Control Panel:

12.1" 4K industrial multi-touch display

25-language interface with voice control

Cybersecurity Level 2 (IEC 62443-3-3)

128GB NVMe storage with automatic cloud sync

Dual Thunderbolt™ 4 ports

Integrated vibration analysis toolkit

Key System Features
Performance Innovations:
✔ Multi-Master Control: Synchronizes up to 32 axes
✔ Precision Regulation: ±0.001% speed accuracy
✔ Adaptive Dynamics: Machine learning-based resonance suppression
✔ Energy Optimization: Real-time loss minimization algorithm

Connectivity Ecosystem:

Standard Interfaces:

8× 10Gbps Ethernet (TSN-enabled)

OPC UA FX over 5G

Time-Sensitive Networking (IEEE 802.1CM)

Optional Modules:

Quantum-safe encryption module

Private 5G industrial network

Satellite synchronization (μs accuracy)

Safety Architecture:

Certified Safety:

SIL3/PL e (Expanded to 12 safety functions)

IEC 61508:2010 compliant

System Reliability:

Triple-redundant control

Predictive failure analysis

Cyber-physical protection

Mechanical Specifications
Enclosure System: IP54 (NEMA 12) standard

Cooling Solution: Phase-change cooling (8000W capacity)

Dimensions: 800 × 2200 × 600mm (W×H×D)

Weight: 350kg (operational weight)

Acoustics: <65dB(A) at 1m

MTBF: >250,000 hours

Core Specifications
Drive Module (ACS800-04-0320-3):

Output Power: 320kW (430HP) at 400V

Output Current: 620A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

200% for 3 seconds

Control Technology: Enhanced Direct Torque Control (DTC)

Efficiency: 98.4% at full load

Switching Frequency: 1-3kHz (adaptive)

P901 Control Panel:

10.1" industrial multi-touch display (1500 nits)

22-language interface with technical dictionaries

Cybersecurity web server (IEC 62443-4-2 compliant)

64GB NVMe data storage with RAID 1

Dual isolated USB-C 3.2 ports

Hardware-encrypted communications

Key System Features
Performance Enhancements:
✔ Ultra-Precise Control: ±0.005% speed accuracy (with encoder)
✔ Adaptive Dynamics: AI-based vibration suppression
✔ Process Optimization: Triple PID with MIMO capability
✔ Energy Intelligence: Real-time efficiency optimization

Connectivity Suite:

Standard Network:

4× 1Gbps Ethernet (PROFINET IRT, EtherNet/IP)

OPC UA FX (Field eXchange)

MQTT Sparkplug B

Optional Protocols:

PROFIBUS DP-V3

EtherCAT G

5G industrial wireless

Safety & Reliability:

Certified Safety:

SIL3/PL e (STO, SS1, SLS, SBC)

ISO 13849-1 Cat.4/PLe

System Protection:

AI-based predictive diagnostics

Dual-redundant safety PLC

Black box event recorder

Mechanical Specifications
Enclosure System: IP21/IP54 hybrid (cabinet-ready)

Cooling Architecture: Liquid-assisted forced cooling

Dimensions: 600 × 2000 × 500mm (W×H×D)

Weight: 280kg (dry weight)

Acoustics: <70dB(A) at 1m

Cooling Capacity: 4000W heat dissipation

Core Specifications
1. ACS800-01-0050-5 Drive Unit

Output Power: 37kW (50HP) at 200V

Output Current: 125A continuous

Input Voltage: 3-phase 200-240V AC (-15%/+10%)

Overload Capacity:

150% for 60 seconds

200% for 3 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 97.6% at full load

Switching Frequency: 1-8kHz (adaptive)

2. D150 Braking Module

Continuous Braking Power: 55kW

Peak Capacity: 110kW (10% duty cycle)

Response Time: <1ms

Protection: Over-temperature monitoring with auto-derating

3. P901 Control Panel

7" sunlight-readable multi-touch display

16-language interface with technical terms

Integrated web server (HTTPS/SSL)

32GB industrial-grade SSD storage

Dual USB 3.0 ports (front/rear)

Key System Features
Performance Enhancements:
✔ Precision Control: ±0.03% speed accuracy
✔ Adaptive Braking: Automatic torque optimization
✔ Process Intelligence: Dual PID controllers with cross-coupling
✔ Energy Management: Regenerative power monitoring

Connectivity Suite:

Standard Interfaces:

PROFINET IRT (2 ports)

EtherNet/IP

OPC UA Pub/Sub

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Wireless LAN

Safety Systems:

Certified Safety:

SIL3/PL e (STO, SS1, SLS)

ISO 13849-1 compliant

Protection Features:

Motor insulation monitoring

Bearing current protection

Adaptive thermal management

Physical Specifications
Enclosure Rating: IP21 (NEMA 1)

Cooling System: Smart fan with dust detection

Dimensions: 400 × 800 × 300mm (W×H×D)

Weight: 42kg (complete system)

Noise Level: <62dB(A) at 1m

Core Specifications
Drive Unit (ACS800-04-0140-3):

Output Power: 140kW (187HP) at 400V

Output Current: 270A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

200% for 3 seconds

Control Technology: Enhanced Direct Torque Control (DTC)

Efficiency: 98.3% at full load

Switching Frequency: 1-4kHz (adaptive)

P901 Control Panel:

10.1" sunlight-readable multi-touch display

22-language interface with technical dictionaries

Industrial-grade web server (IEC 62443-4-2 compliant)

64GB NVMe data storage with RAID protection

Dual isolated USB-C 3.2 ports

Hardware-encrypted data communications

Key System Features
Performance Enhancements:
✔ Precision Control: ±0.01% speed accuracy (with encoder)
✔ Adaptive Dynamics: Machine learning-based vibration suppression
✔ Process Optimization: Quad-channel PID with MIMO capability
✔ Energy Intelligence: Real-time efficiency optimization

Connectivity Suite:

Standard Network:

4× 2.5Gbps Ethernet (TSN-enabled)

OPC UA FX (Field eXchange)

MQTT Sparkplug B

Optional Protocols:

PROFIBUS DP-V3 with SiS

EtherCAT G

5G industrial wireless

Safety & Reliability:

Certified Safety:

SIL3/PL e (Expanded safety suite)

ISO 13849-1 Cat.4/PLe

System Protection:

AI-based predictive fault detection

Dual-redundant safety PLC

Black box recorder (last 100 fault events)

Mechanical Specifications
Enclosure System: IP21/IP54 hybrid (cabinet-ready)

Cooling Architecture: Phase-change assisted liquid cooling

Dimensions: 600 × 1800 × 500mm (W×H×D)

Weight: 210kg (dry weight)

Acoustics: <68dB(A) at 1m

Cooling Capacity: 3500W heat dissipation

Core Specifications
Drive Unit (ACS800-04-0075-3):

Output Power: 75kW (100HP) at 400V

Output Current: 146A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 98.1% at full load

Switching Frequency: 1-5kHz (adjustable)

P901 Control Panel:

7" high-resolution industrial touchscreen (1500 nits)

Multi-language interface (18 languages)

Integrated web server with cybersecurity features

32GB solid-state data logging

Dual USB 3.2 configuration ports

Real-time clock with supercapacitor backup

Key System Features
Advanced Performance:
✔ Ultra-Precise Control: ±0.02% speed accuracy
✔ Adaptive Control: 16 application-specific macros
✔ Process Optimization: Triple PID controllers with AI tuning
✔ Harmonic Mitigation: <3% THD with active front end option

Connectivity & Integration:

Standard Interfaces:

2× 1Gbps Ethernet (PROFINET IRT, EtherNet/IP)

OPC UA Pub/Sub

IEC 61850 protocol support

Optional Modules:

PROFIBUS DP-V3

BACnet/SC

5G wireless module

Safety Systems:

Certified Safety:

SIL3/PL e (STO, SS1, SLS, SBC)

ISO 13849-1, IEC 62061 compliant

Redundant Architecture:

Dual safety processors

Watchdog monitoring

Mechanical Specifications
Enclosure Rating: IP21 (cabinet-mounted)

Cooling System: Hybrid liquid/forced air cooling

Dimensions: 450 × 900 × 400mm (W×H×D)

Weight: 68kg (complete system)

Noise Level: <65dB at 1m

Cooling Airflow: 2000m³/h (with filters)

Core Specifications
Drive Unit (ACS800-01-0025-3):

Output Power: 18.5kW (25HP) at 400V

Output Current: 39A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity:

150% for 60 seconds

200% for 3 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 97.2% at full load

Switching Frequency: 1-8kHz (adjustable)

P901 Control Panel:

7" high-brightness TFT touchscreen (1280×800)

Multi-language interface (16 languages)

Integrated web server with HTTPS security

16GB non-volatile data storage

Dual USB 3.1 configuration ports

Real-time predictive maintenance functions

Key System Features
Advanced Performance:
✔ Precision Control: ±0.05% speed accuracy
✔ Adaptive Programming: 12 application macros
✔ Process Optimization: Dual PID controllers with fuzzy logic
✔ Energy Management: kWh/MWh consumption monitoring

Connectivity & Integration:

Standard Interfaces:

PROFINET IRT (2 ports)

EtherNet/IP

OPC UA over TCP/IP

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Wireless LAN

Safety Systems:

Integrated Safety:

Safe Torque Off (STO) - SIL3/PL e

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Redundant Safety Circuits

Continuous Self-Monitoring

Mechanical Specifications
Enclosure Rating: IP21 (NEMA 1)

Cooling System: Smart temperature-controlled fans

Dimensions: 300 × 700 × 250mm (W×H×D)

Weight: 25kg (complete system)

Noise Level: <60dB at 1m

Core Specifications
Drive Unit (ACS800-01-0003-3):

Output Power: 2.2kW (3HP) at 400V

Output Current: 5.5A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: >96% at full load

Switching Frequency: 1-16kHz (adjustable)

P901 Control Panel:

7" high-resolution color touchscreen

Multi-language interface (12 languages)

Integrated web server functionality

8GB data logging capacity

USB 3.0 configuration port

Real-time clock with battery backup

Key System Features
Advanced Control:
✔ Precision Regulation: ±0.2% speed accuracy
✔ Application Macros: 6 pre-programmed configurations
✔ Process Control: Single PID controller with auto-tuning
✔ Energy Optimization: Power consumption monitoring

Connectivity:

Standard Interfaces:

Modbus RTU (RS485)

Ethernet

Optional Modules:

PROFIBUS DP

PROFINET IRT

DeviceNet

Safety Systems:

Safe Torque Off (STO) - SIL3 certified

Motor thermal protection

Short-circuit protection

Phase loss detection

Mechanical Specifications
Enclosure Rating: IP21 (NEMA 1)

Dimensions: 200 × 400 × 180mm (W×H×D)

Weight: 8.5kg (complete system)

Cooling: Natural convection

Noise Level: <55dB at 1m
