Key Specifications
Power Rating: 1.1 kW (1.5 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 3.0 A

Overload Capacity: 150% for 3 seconds

Control Technology: Sensorless vector control

Switching Frequency: 2-16 kHz (adjustable)

Efficiency: >97%

Main Features
✔ Advanced Motor Control

Direct Torque Control (DTC) technology

Automatic Motor Adaptation (AMA)

Torque boost function (±3% accuracy)

Flying start capability

✔ Application Flexibility

5 pre-programmed application macros

Built-in PID controller

Customizable application programs

✔ Protection & Safety

Motor thermal protection (PTC/KTY supported)

Short circuit and ground fault protection

Safe Torque Off (STO) option (SIL3/PL e)

✔ Connectivity Options

Standard RS485 (Modbus RTU)

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics
Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.7 kg

Enclosure Rating: IP20 (open type)

Cooling Method: Natural convection

Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

Key Specifications
Power Rating: 0.55 kW (0.75 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 1.7 A

Overload Capacity: 150% for 3 seconds

Control Technology: Sensorless vector control

Switching Frequency: 2-16 kHz (adjustable)

Efficiency: >97%

Main Features
✔ Advanced Motor Control

Direct Torque Control (DTC) technology

Automatic Motor Adaptation (AMA)

Torque boost function

Flying start capability

✔ Application Flexibility

5 pre-programmed application macros

Built-in PID controller

Customizable application programs

✔ Protection & Safety

Motor thermal protection (PTC input)

Short circuit and ground fault protection

Safe Torque Off (STO) option

✔ Connectivity Options

Standard RS485 (Modbus RTU)

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics
Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.65 kg

Enclosure Rating: IP20 (open type)

Cooling Method: Natural convection

Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

Key Specifications
Power Rating: 0.75 kW (1 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 2.1 A

Overload Capacity: 150% for 3 seconds

Control Technology: Sensorless vector control

Switching Frequency: 2-16 kHz (adjustable)

Efficiency: >97%

Main Features
✔ Advanced Motor Control

Direct Torque Control (DTC) technology

Automatic motor adaptation (AMA)

Torque boost function (±3% accuracy)

Flying start capability

✔ Application Flexibility

5 pre-programmed application macros

Built-in PID controller

Customizable application programs

✔ Protection & Safety

Motor thermal protection (PTC/KTY supported)

Short circuit and ground fault protection

Safe Torque Off (STO) option (SIL3/PL e)

✔ Connectivity Options

Standard RS485 (Modbus RTU)

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics
Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.7 kg

Enclosure Rating: IP20 (open type)

Cooling Method: Natural convection

Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

Key Specifications
Power Rating: 4 kW (5 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 9.5A

Overload Capacity: 150% for 3 seconds

Control Method: Sensorless vector control

Switching Frequency: 2-16kHz (adjustable)

Efficiency: >97%

Main Features
Advanced Motor Control

Precise speed regulation (±0.5% accuracy)

Automatic Motor Adaptation (AMA)

Torque boost function

Flying start capability

Application Flexibility

5 pre-programmed application macros

Built-in PID controller

Customizable logic functions

Protection & Safety

Motor thermal protection (PTC/KTY)

Short circuit and ground fault protection

Safe Torque Off (STO) option

Connectivity Options

RS485 (Modbus RTU) standard

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics
Dimensions: 150 × 200 × 165mm (W×H×D)

Weight: 2.1kg

Enclosure Rating: IP20 (open type)

Cooling Method: Natural convection

Ambient Temperature: -10°C to +50°C (14°F to 122°F)

Key Specifications

Power Rating: 55 kW (75 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 110 A

Overload Capacity: 150% for 3 seconds

Control Method: Sensorless vector control

Switching Frequency: 2-16 kHz (adjustable)

Main Features

1. Advanced Motor Control

Direct Torque Control (DTC) technology

Automatic motor adaptation (AMA)

Torque control mode (±3% accuracy)

Flying start function

2. Application-Specific Functions

Multiple application macros

Customizable logic functions

Built-in PID controller

Pump and fan control curves

3. Enhanced Connectivity

Standard RS485 (Modbus RTU)

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

USB service port

Physical Characteristics

Enclosure Rating: IP20 (open type)

Dimensions: 350 × 482 × 227 mm (W×H×D)

Weight: 18 kg

Cooling Method: Forced air cooling

Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

Key Specifications
✔ Power Rating: 0.75 kW (1 HP)
✔ Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz
✔ Output Current: 2.1 A
✔ Overload Capacity: 150% for 3 seconds
✔ Control Method: Sensorless Vector Control (DTC option available)
✔ Switching Frequency: 2–16 kHz (adjustable)
✔ Efficiency: >97%

Main Features
1. Advanced Motor Control
Sensorless vector control for precise speed regulation (±0.5% accuracy)

Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback

Torque boost & flying start – ensures smooth operation under load

2. Application Flexibility
Pre-programmed macros (pump, fan, conveyor) for quick setup

Built-in PID controller for process control (pressure, flow, temperature)

Customizable logic via free function blocks

3. Protection & Safety
Motor thermal protection (PTC/KTY input)

Short-circuit, overvoltage, and ground fault protection

Safe Torque Off (STO) – SIL3/PL e safety compliance

4. Connectivity & Control
Standard RS485 (Modbus RTU)

2 analog inputs (0–10V/4–20mA), 4 digital inputs, 1 relay output

Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen)

5. Compact & Robust Design
IP20 enclosure (dust protected)

Optional IP66/NEMA 4X kit for harsh environments

Built-in EMC filter (Class A compliance)

Physical & Environmental Specs
Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.7 kg

Cooling: Convection cooling (fanless)

Ambient Temp: -10°C to +50°C (14°F to 122°F)

Key Specifications:

Power Rating: 1.5 kW (2 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 3.6 A

Overload Capacity: 150% for 3 seconds

Control Technology: Sensorless vector control

Switching Frequency: 2-16 kHz (adjustable)

Main Features:
✔ Advanced Motor Control:

Direct Torque Control (DTC) technology

Automatic motor adaptation (AMA)

Torque boost function

Flying start capability

✔ Application Flexibility:

5 pre-programmed application macros

Built-in PID controller

Customizable application programs

✔ Protection & Safety:

Motor thermal protection (PTC/KTY)

Short circuit and ground fault protection

Safe Torque Off (STO) option

✔ Connectivity Options:

RS485 (Modbus RTU) standard

Optional fieldbus adapters:

PROFIBUS DP

DeviceNet

CANopen

Physical Characteristics:

Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.8 kg

Enclosure Rating: IP20 (open type)

Cooling Method: Natural convection

Ambient Temperature: -10°C to +50°C (14°F to 122°F)

Key Specifications
Power Rating: 1.5 kW (2 HP)

Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz

Output Current: 3.6 A

Overload Capacity: 150% for 3 seconds

Control Method: Scalar (V/f) control

Switching Frequency: 2–16 kHz (adjustable)

Efficiency: >96%

Main Features
✔ Reliable Motor Control

V/f control with torque boost

Automatic Energy Optimizer for efficiency

DC braking capability

✔ Application Flexibility

3 preset speed settings

Basic PID controller

Customizable acceleration/deceleration ramps

✔ Protection Features

Motor thermal protection

Short-circuit and overcurrent protection

Ground fault detection

✔ Standard Interfaces

2 analog inputs (0–10V/4–20mA)

3 digital inputs

1 relay output

RS485 (Modbus RTU) communication

✔ Compact Design

IP20 enclosure

Lightweight (1.1 kg)

Convection cooling (fanless)

Physical & Environmental Specs
Dimensions: 150 × 200 × 165 mm (W×H×D)

Weight: 1.1 kg

Cooling: Natural convection

Ambient Temp: 0°C to +40°C (32°F to 104°F)

Key Specifications
Power Rating: 1.5 kW (2 HP)

Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz

Output Current: 3.6 A

Overload Capacity: 150% for 3 seconds

Control Method: Sensorless Vector Control (DTC option available)

Switching Frequency: 2–16 kHz (adjustable)

Efficiency: >97%

Main Features
✔ Advanced Motor Control

Sensorless vector control for precise speed regulation (±0.5% accuracy)

Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback

Torque boost & flying start – ensures smooth operation under load

✔ Application Flexibility

Pre-programmed macros (pump, fan, conveyor) for quick setup

Built-in PID controller for process control (pressure, flow, temperature)

Customizable logic via free function blocks

✔ Protection & Safety

Motor thermal protection (PTC/KTY input)

Short-circuit, overvoltage, and ground fault protection

Safe Torque Off (STO) – SIL3/PL e safety compliance

✔ Connectivity & Control

Standard RS485 (Modbus RTU)

2 analog inputs (0–10V/4–20mA), 4 digital inputs, 1 relay output

Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen)

✔ Compact & Robust Design

IP20 enclosure (dust protected)

Optional IP66/NEMA 4X kit for harsh environments

Built-in EMC filter (Class A compliance)

Physical & Environmental Specs
Dimensions: 70 × 170 × 145 mm (W×H×D)

Weight: 0.8 kg

Cooling: Convection cooling (fanless)

Ambient Temp: -10°C to +50°C (14°F to 122°F)

Key Specifications

Power Rating: 0.1 kW (0.13 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 0.6A

Overload Capacity: 150% for 3 seconds

Control Method: Sensorless vector control

Switching Frequency: Up to 16kHz (adjustable)

Main Features

1. Compact & Efficient Design

Industry's smallest footprint in its class (70×170×145mm)

Lightweight (0.6kg) IP20 enclosure

Optional IP66/NEMA 4X kit available

Built-in EMC filter (Class A)

2. Advanced Motor Control

Sensorless vector control technology

Automatic motor adaptation (AMA)

Flying start capability

Torque boost function

3. Application Flexibility

3 pre-programmed application macros

Customizable application programs

Built-in PID controller

Standard Interfaces

Control Terminals:

2 analog inputs (0-10V/4-20mA)

4 digital inputs

1 relay output

Communication:

RS485 (Modbus RTU standard)

Optional fieldbus adapters available

Physical Characteristics

Dimensions: 70×170×145mm (W×H×D)

Weight: 0.6kg

Cooling: Natural convection

Ambient Temperature: -10°C to +50°C
