Key Specifications
Parameter Specification
Output Current 246A
Rated Power 132kW (400V, 4-pole motor)
Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz
Enclosure IP21 (open chassis)
Control Methods Sensorless Vector Control (SLVC)
Overload 110% for 60 seconds (heavy-duty rating)
Communication Modbus RTU standard + optional fieldbus
Technical Highlights
✔ High-Efficiency Design

98% typical efficiency at full load

Automatic energy optimization for variable torque loads

✔ Advanced Protection Features

I²t motor thermal protection

Built-in DC choke (harmonic mitigation)

Ground fault and short-circuit protection

✔ Industrial-Grade Construction

Reinforced cooling system with temperature-controlled fans

-10°C to +40°C operation (with derating above 40°C)

Compact footprint for power class (WxHxD: 350×450×250mm)

✔ Smart Control Capabilities

Built-in PID controller with auto-tuning

Customizable application macros

Predictive maintenance monitoring
