The Schneider Electric ATS22D62Q is a Soft Starter from the Altistart 22 series, designed for three-phase asynchronous motors. This model is rated for 62 A and provides controlled acceleration and deceleration to reduce mechanical stress on driven equipment and limit inrush current.

Key Specifications
Power Rating: 2.5 kW (3 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 6.5 A

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Encoder Interface: N671 module included

Main Features
✔ Precision Motion Control

Closed-loop speed control (±0.005% accuracy)

Torque control (±0.5% accuracy)

Automatic motor adaptation

Position control capability

✔ N671 Encoder Module

Supports incremental encoders (5V/24V)

Resolution up to 4096 ppr

Differential (RS422) and single-ended inputs

LED status indicators

✔ Application Flexibility

Multiple pre-programmed motion profiles

Electronic gearing function

Built-in PID controller

Customizable application programming

✔ Protection & Safety

Motor thermal protection

Encoder loss detection

Safe Torque Off (STO)

Overvoltage/undervoltage protection

Physical Characteristics
Drive Dimensions: 245 × 482 × 227 mm (W×H×D)

Weight: 8.5 kg (complete system)

Enclosure Rating: IP21

Cooling Method: Convection cooling

Ambient Temperature: 0-40°C (32-104°F)
