Key Specifications & Parameters Parameter Specification / Description Product Type Separate in-line pressure reduction and noise attenuation device Design Principle Multi-stage, multi-orifice pressure drop modules creating sequential pressure reductions Installation Installed downstream of a control valve in the pipeline Noise Reduction Up to 20-40 dBA compared to standard valve configurations Pressure Control Capable of handling extremely high pressure drops (up to 5000 psi/345 bar+) Size Range Typically 1" to 24" (DN 25 to DN 600) Pressure Ratings ANSI Class 150 to 4500, including special high-pressure designs Temperature Range -450° to 1200°F (-268° to 649°C) depending on materials and design Materials Standard: Carbon Steel (WCB) Common Options: Stainless Steel (304, 316, F316), Alloy Steel (WC9, C12A), Duplex Stainless Steel, Nickel Alloys Flow Capacity High Cv values maintained while achieving pressure breakdown Configurations Standard: Single-unit design Dual-Range: Manifolded configurations for varying flow conditions

The ABB SNAT617CHC control module is a high-performance solution designed for advanced industrial automation applications, offering precise control and enhanced efficiency.

ABBYPQ203A connection board is a high-performance connection device specially designed for automation control systems, which is suitable for various industrial environments. It can achieve efficient data transmission and signal conversion to ensure the stable operation of the system.
