Technical Specifications / Parameters Parameter Specification for P163A & P164 Model Fisher P163A (Atmospheric Vent), Fisher P164 (Vented) Type Direct-Acting, Spring-Loaded, Backpressure Pilot Function Controls the upstream pressure of a main pilot-operated backpressure regulator or relief valve. Sensed Pressure Upstream (Inlet) Pressure of the main regulator. Vent Configuration P163A: Vents to Atmosphere. P164: Vents to a separate, lower-pressure vent line. Maximum Inlet Pressure (to Pilot) Up to 400 psig (27.6 bar) for standard models. Set Pressure Range Varies with spring. Common ranges are available from very low pressures (inches of water) up to 400 psig. Supply Pressure Connection 1/4" NPT (This is the loading pressure from the main valve's relay). Sense Pressure Connection 1/4" NPT (Connected to the upstream process pressure). Vent Connection P163A: Typically has a vent screen or open port. P164: 1/4" NPT for connection to a vent header. Diaphragm Material Butyl (standard for natural gas), EPDM, Nitrile. Body Material Aluminum Spring Material Music Wire (standard, with corrosion-resistant coating). Temperature Range -20°F to +150°F (-29°C to +66°C) - standard elastomers.

The ABB ACS380-040C-12A6-4+K475 is a configured 12.6 Ampere, 5.5 kW (7.5 HP) variable frequency drive from the ACS380 series, which is specifically engineered for Material Handling applications. This package includes a key factory-installed option that enhances its connectivity for modern automation systems.

The Yokogawa ADV161 Digital Input Module is a high-performance PLC component designed for seamless integration into industrial automation systems. It offers robust digital input functionality, ensuring reliable data acquisition and control in demanding environments.
