Eaton DILM580 110-250VAC/DC – High-Current Universal Coil Power Contactor The Eaton DILM580 110-250VAC/DC is a three-pole, high-power contactor from the DILM series, featuring a versatile universal (AC/DC) operating coil. This design is engineered to provide maximum flexibility in control circuit design for applications requiring the switching of extremely high currents.

The Mitsubishi RX40C7-TS is a high-performance industrial-grade panel computer from Mitsubishi Electric's RX Series, designed for mission-critical automation applications in harsh industrial environments. This model features rugged construction, powerful computing performance, and extensive connectivity options for seamless integration with industrial control systems.

Technical Parameters Parameter Specification Product Model XNE-16DO-24VDC-0.5A-P Product Family Eaton XN System (Electronic Module) Module Type Digital Output Module Number of Channels 16 Output Type Sourcing (PNP) Output Voltage 24 V DC (Nominal) Load Current per Channel 0.5 A (Maximum) Total Module Current 4 A (Maximum, sum of all channels) Short-Circuit Protection Yes (Per channel, electronically) Load Type Resistive, Inductive, Lamp Load Isolation Channel-to-Bus: Yes (Optically isolated) Connection Method Removable screw terminal block Module Power Supply 24 V DC (via the XN system base or terminal block) Status Indicators - PWR (Power): Green LED - SF (System Fault): Red LED - CHx (Channel Status): Green LED per channel IP Rating IP20 (for installation inside a control cabinet) Mounting On an XN system base unit, mounted on a standard 35 mm DIN rail Operating Temperature -25 °C to +60 °C (-13 °F to 140 °F) Standards & Certifications CE, UL, cULus, RoHS compliant
