The Schneider Electric LC1E400/220V is a heavy‑duty 3‑pole magnetic contactor from the TeSys E series designed for robust switching and control of high‑current three‑phase loads. With a rated operational current of 400 A and a 220 V AC control coil, this contactor is suitable for large motors, power circuits, and industrial electrical systems.

The Schneider Electric NSX250N is a 3‑pole molded case circuit breaker (MCCB) designed for low‑voltage distribution and protection applications. It provides reliable protection against overload, short‑circuit, and electrical faults in three‑phase power systems.

The Schneider Electric NSX160N 3‑Pole 160 A is a high‑performance molded case circuit breaker (MCCB) designed for protection and control of low‑voltage electrical distribution systems.

The Schneider Electric LC1D80/220V is a 3‑pole magnetic contactor from the TeSys D series designed for reliable switching and control of three‑phase electrical loads. With a rated operational current of 80 A and a 220 V AC control coil, this contactor is suitable for controlling motors, resistive loads, and power circuits in industrial and commercial environments.

The Schneider Electric Compact NSX100F 3‑Pole 63A is a molded case circuit breaker (MCCB) designed for low‑voltage industrial and commercial power distribution systems.

The Schneider Electric TeSys F LC1F1700P7 is a heavy‑duty 3‑pole magnetic contactor designed for high‑current power switching and control in industrial electrical systems

The Schneider Electric TeSys F LC1F1700M7 is a heavy‑duty 3‑pole magnetic contactor designed for high‑current switching applications in industrial electrical systems.

The Schneider Electric LC1D95E7C is a 3‑pole AC magnetic contactor from the TeSys D series, engineered for reliable switching and control of three‑phase electric motors and power circuits in industrial and commercial environments

The Schneider Electric LC1D95Q7C is a 3‑pole magnetic contactor from the TeSys D series designed for motor control and general power switching applications.

Specifications Parameter Specification Brand Schneider Electric Series TeSys D Model / Type LC1D95CC5C Device Type Magnetic Contactor Number of Poles 3‑Pole (3 main NO power contacts) Rated Operational Current (Ie) 95 A (AC‑3) Rated Operational Voltage (Ue) ≤ 690 V AC Utilization Category AC‑1 / AC‑3 / AC‑4 Auxiliary Contacts 1 NO + 1 NC Coil Voltage Options DC or AC variants (e.g., 24 V DC, 110–415 V AC) Rated Insulation Voltage (Ui) 1000 V AC Rated Impulse Withstand Voltage (Uimp) 8 kV Motor Power Rating (AC‑3) Up to 45 kW @ 380–400 V AC Contact Configuration 3 main NO + auxiliary contacts Mechanical Life ~10,000,000 operations Electrical Life (AC‑3) ~1,000,000 operations Operating Frequency Up to ~3600 operations/hour Mounting DIN‑rail or panel mount Connection Type Screw / clamp terminals Standards Compliance IEC/EN 60947‑4‑1, UL, CSA, CCC Protection Degree IP20 Operating Temperature Range −40 °C to 60 °C Pollution Degree 3
