The Schneider Electric TM3AI4G is a 4-channel, high-speed analog input module for the Modicon TM3 modular I/O system. Designed for precision measurement in dynamic industrial processes, it acquires analog voltage or current signals from sensors and transmitters with high speed and accuracy.

The SIEMENS SCALANCE X224 is an advanced managed industrial Ethernet switch designed for robust and reliable network connectivity in demanding industrial environments. It supports multiple communication protocols and offers comprehensive network management tools.

Key Parameters
Core Specifications
Power: 40kW (55HP)

Input: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 80A

Overload: 150% for 60s

Control: DTC (Direct Torque Control)

Efficiency: >98%

Modules
P901 Brake Chopper

Braking power: 40kW cont. / 60kW peak (60s)

Requires external resistor

N661 Encoder Interface

Supports incremental encoders

Resolution: Up to 4096 ppr

Protocols: RS422/TTL

Performance
Speed accuracy: ±0.01% (with encoder)

Torque accuracy: ±1%

Switching freq.: 1-12kHz (adjustable)

Physical
Dimensions: 482×245×227mm (H×W×D)

Weight: 18kg

Cooling: Forced air

Ambient Temp: 0-40°C

Certifications
CE, UL, cUL

SIL3/PL e
