Technical Parameters Parameter Specification Product Type Valve-Regulated Lead-Acid (VRLA), GFM/AGM, Maintenance-Free Nominal Voltage 12 V Nominal Capacity 100 Ah (Typically rated at the 20-hour discharge rate, C/20, to 10.5V) Terminal Type Standard (e.g., M8 stud terminals or F10 fast-on tabs) Approximate Dimensions (L x W x H) ~ 330 x 172 x 215 mm (12.99" x 6.77" x 8.46") [Must verify from datasheet] Approximate Weight ~ 28 - 31 kg (62 - 68 lbs) Design Life 5 - 10 years (at 25°C / 77°F, highly dependent on cycle depth and charging) Max. Discharge Current Typically 500A for 5 seconds Self-Discharge ≤ 3% per month at 25°C (77°F) Operating Temperature Range Discharge: -15°C to 50°C (5°F to 122°F) Charge: -15°C to 40°C (5°F to 104°F) Storage: -15°C to 40°C (5°F to 104°F) Float Charge Voltage 13.5 - 13.8 V DC (at 25°C / 77°F) Cycle Use Charge Voltage 14.4 - 15.0 V DC (at 25°C / 77°F)

Technical Parameters) Parameter Specification Product Type Sealed Lead-Acid (SLA), AGM, Deep-Cycle Nominal Voltage 12 V Nominal Capacity 100 Ah (Typically rated at the 20-hour discharge rate, C/20) Terminal Type Standard (e.g., M8 stud terminals or similar) Approximate Dimensions (L x W x H) ~ 330 x 172 x 215 mm (12.99" x 6.77" x 8.46") [Must verify from datasheet] Approximate Weight ~ 28 - 31 kg (62 - 68 lbs) Design Life 5 - 10 years (at 25°C / 77°F, depending on cycle depth and charging) Max. Discharge Current Typically 500A for 5 seconds Self-Discharge ≤ 3% per month at 25°C (77°F) Operating Temperature Range Discharge: -15°C to 50°C (5°F to 122°F) Charge: -15°C to 40°C (5°F to 104°F) Storage: -15°C to 40°C (5°F to 104°F) Float Charge Voltage 13.5 - 13.8 V DC (at 25°C / 77°F) Cycle Use Charge Voltage 14.4 - 15.0 V DC (at 25°C / 77°F)

Technical Parameters Parameter Specification Product Series Eaton 5P Product Type Line-Interactive UPS Topology Line-Interactive Nominal Output Power 1550 VA Nominal Output Power in Watts 930 W (at a typical power factor of 0.6) Input Voltage: 230 V AC (for specific regional variants) Frequency: 50 Hz (for specific regional variants) Connector: IEC 60320 C14 Output Voltage on Battery: Simulated Sine Wave Output Connectors: IEC 60320 C13 outlets (typically 6-8) Typical Runtime at Full Load A few minutes (e.g., 5-10 minutes, exact time depends on load) Battery Type: Sealed, maintenance-free Lead-Acid battery Replacement: User-replaceable Automatic Voltage Regulation (AVR) Yes (Corrects brownouts and overvoltages without using the battery) Communications USB port for connection to a computer for graceful shutdown Display & Interface LED status indicators for power and battery status Form Factor Compact Tower Typical Applications Workstations, POS Systems, Network Devices (routers, switches), Home Office

Technical Parameters Parameter Specification Product Series Eaton 5P Product Type Line-Interactive UPS Topology Line-Interactive Nominal Output Power 1150 VA Nominal Output Power in Watts 690 W (at a typical power factor of 0.6) Input Voltage: 230 V AC (for specific regional variants) Frequency: 50 Hz (for specific regional variants) Connector: IEC 60320 C14 Output Voltage on Battery: Simulated Sine Wave Output Connectors: IEC 60320 C13 outlets (typically 6-8) Typical Runtime at Full Load A few minutes (e.g., 5-10 minutes, exact time depends on load) Battery Type: Sealed, maintenance-free Lead-Acid battery Replacement: User-replaceable Automatic Voltage Regulation (AVR) Yes (Corrects brownouts and overvoltages without using the battery) Communications USB port for connection to a computer for graceful shutdown Display & Interface LED status indicators for power and battery status Form Factor Compact Tower Typical Applications Workstations, POS Systems, Network Devices (routers, switches), Home Office

Technical Parameters) Parameter Specification Product Series Eaton 5P Product Type Line-Interactive UPS Topology Line-Interactive Nominal Output Power 850 VA Nominal Output Power in Watts 510 W (at a typical power factor of 0.6) Input Voltage: 230 V AC (for specific regional variants) Frequency: 50 Hz (for specific regional variants) Connector: IEC 60320 C14 Output Voltage on Battery: Simulated Sine Wave Output Connectors: Multiple IEC 60320 C13 outlets (typically 6-8) Typical Runtime at Full Load A few minutes (e.g., 5-10 minutes, exact time depends on load; longer at lower loads) Battery Type: Sealed, maintenance-free Lead-Acid battery Replacement: User-replaceable, hot-swappable cartridge Automatic Voltage Regulation (AVR) Yes (Corrects brownouts and overvoltages without using the battery) Communications USB port for connection to a computer for graceful shutdown Display & Interface LED status indicators for power and battery status Form Factor Compact Tower Typical Applications Desktop Workstations, Entry-level Servers, POS Systems, Network Devices

Technical Parameters Parameter Specification Product Series Eaton 5P Product Type Line-Interactive UPS Topology Line-Interactive Nominal Output Power 650 VA Nominal Output Power in Watts 390 W (at a typical power factor of 0.6) Input Voltage: 230 V AC (for specific regional variants) Frequency: 50 Hz (for specific regional variants) Connector: IEC 60320 C14 Output Voltage on Battery: Simulated Sine Wave Output Connectors: IEC 60320 C13 outlets (typically 4-6) Typical Runtime at Full Load A few minutes (e.g., 5-10 minutes, exact time depends on load) Battery Type: Sealed, maintenance-free Lead-Acid battery Replacement: User-replaceable Automatic Voltage Regulation (AVR) Yes (Corrects brownouts and overvoltages without using the battery) Communications USB port for connection to a computer for graceful shutdown Display & Interface LED status indicators for power and battery status Form Factor Compact Tower Typical Applications Workstations, POS Systems, Network Devices (routers, switches), Home Office Warranty Typically 2 years

Technical Parameters Parameter Typical Specification (To be verified from datasheet) Product Type Fixed, Polarized Electrolytic Capacitor Capacitance 1000 µF (Microfarads) Capacitance Tolerance Typically ±20% (e.g., M tolerance) Rated Voltage (WV) e.g., 16V DC, 25V DC, 35V DC, 50V DC (This is a CRITICAL parameter to confirm) Operating Temperature Range Typically -40°C to +85°C or +105°C Leakage Current Specified by the manufacturer's formula (e.g., I ≤ 0.01CV or 3 µA, whichever is greater) Dissipation Factor (tan δ) Specified at 120 Hz and 20°C (e.g., 0.12 max) Lead Spacing e.g., 3.5 mm, 5 mm, 10 mm (Standard radial distances) Polarization Polarized (Negative lead is typically marked by a stripe on the casing) Lifetime Typically 1000 to 5000 hours at maximum rated temperature

Technical Parameters Parameter Specification Product Name Eaton Network-M3 Network Management Card Product Type Internal UPS Communication Card Compatibility Eaton 3S, 5P, 5S, 5SC, 9PX, 9SX, and other series UPS (Check compatibility list) Network Interface 10/100 Mbps Ethernet (RJ-45 connector) Management Protocols HTTP/HTTPS, SSH, SNMP v1/v3, Telnet, DHCP/BOOTP, DNS Shutdown Support Supports graceful shutdown for Windows, Linux, VMware, Mac OS, and other major operating systems Environmental Monitoring Yes (via RJ-11 port for optional EATON T/H probe) Additional I/O One Dry Contact relay output (for external alarm) Power Supply Powered directly by the host UPS Configuration Via integrated web browser interface or Eaton software (e.g., Intelligent Power Manager) Security Features User authentication (multiple user levels), SSL/SSH encryption, SNMP v3 Firmware Field-upgradable Certifications CE, cULus, RoHS

Technical Parameters Parameter Specification Product Series Eaton 93E Product Type Metered, Switched (by branch) PDU, Vertical (0U) Nominal Input Power 40 kVA / 40 kW (Assume PF=1.0) Input Type 3-Phase + Neutral + Ground Input Voltage 200/208 V AC or 400/415 V AC (Specific voltage to be confirmed) Input Current Typically 100 A or 60 A (depending on the specific voltage rating) Frequency 50/60 Hz Output Outlets Multiple outlet banks (Typically IEC C13/C19, NEMA, or a combination) Branch Circuit Breakers Multiple branches (e.g., 1P or 3P breakers, 16A, 20A, or 32A) Monitoring & Control Metering: Input current (per phase), voltage (L-N, L-L), power (kW), energy (kWh), power factor Switching: Individual branch circuit control (ON/OFF/reboot) Communication: Built-in Network Card (10/100/1000 Ethernet) Protocols: Web, SSH, SNMP, Telnet Display Local LCD for status and basic metrics Form Factor Vertical (0U) Mounting Zero U, vertical mounting in 19-inch rack Management Features Power sequencing, alarm thresholds, event logging, user access control Standards Compliance UL 60950-1, cULus, CE, RoHS

Technical Parameters Parameter Specification Product Series Eaton PW9100 iSeries Product Type Intelligent, Switched PDU with Environmental Monitoring Nominal Input Power 1000W (Total load capacity) Input Connection Plug: IEC 60320 C14 or C20 (Region-specific cord attached) Input Voltage 100-125 V AC / 200-240 V AC (Auto-sensing) Input Current 12A @ 100V / 16A @ 125V / 10A @ 200-240V Frequency 50/60 Hz Output Outlets 10 x IEC C13 (Typical configuration, may vary) Outlet Control Individual outlet switching (per outlet ON/OFF/reboot) Monitoring & Control Metering: Aggregate current (A), voltage (V), power (kW), energy (kWh) Switching: Individual outlet control Environmental: Ports for external temperature & humidity sensors Communication: Built-in 10/100 Mbps Network Card Protocols: Web, SSH, SNMP, Telnet Display Local backlit LCD for status and metrics Form Factor Horizontal 2U Rackmount Mounting 19-inch rack, 2 Rack Units (2U) high Management Features Power sequencing, alarm thresholds, event logging, user access control Standards Compliance UL 60950-1, cULus, CE, RoHS
