The Schneider Electric TSXDEY16T2 digital input module is a high-performance input device designed for industrial automation control systems. It can efficiently convert field signals into electrical signals that can be recognized by PLC systems, and is widely used in manufacturing, energy, transportation and other industries.

The SIEMENS 6ES7351-1AH01-0AE0 Precision Positioning Module is designed for rapid and creep feed drive control, featuring an integrated configuration package on CD for streamlined setup and operation.

Category Parameter Specification Application Protected Circuit 2-wire Analog signals (e.g., 4-20 mA loops) Connection In-series with the signal line Electrical Characteristics Nominal Voltage 8 V DC Max. Continuous Operating Voltage Uc 12 V DC Nominal Current ≤ 250 mA Voltage Drop Typically < 1 V Insertion Loss Typically negligible Surge Protection Performance Test Waveform (IEC 61643-21) 1.2/50 μs (Voltage) - 8/20 μs (Current) Nominal Discharge Current (In) 5 kA (8/20 μs) Max. Discharge Current (Imax) 10 kA (8/20 μs) Protection Level (Up) < 25 V (at In = 5 kA, 8/20 μs) General Data Number of Poles / Channels 2 (for series connection in one signal loop) Connection Type Screw terminals Mounting 35 mm DIN Rail Housing Material Plastic Operating Temperature -40 °C to +80 °C Standards / Approvals IEC 61643-21, CE
