Technical Parameters Parameter Specification Model Fisher 3025C Type Pilot-Operated Pressure Reducing Regulator Body Materials Ductile Iron (Standard), Cast Iron, Carbon Steel End Connections Flanged (ANSI Class 150, 300, 600); Butt-Weld Size Range 2" to 8" (DN 50 to DN 200) Maximum Inlet Pressure (P1) Up to 1440 psig (99 bar) for ANSI 600 models. Outlet Pressure Range (P2) Depends on the pilot spring. Wide range available, from a few psig up to 400+ psig. Temperature Range -20°F to 150°F (-29°C to 66°C) with standard Buna-N diaphragms. Flow Capacity (Cv) Very high. Example (4" Size): Cv ~ 240 Accuracy (Droop) Excellent, typically less than 5% of the setpoint due to pilot-operated design. Pilot Options Available in various setpoint ranges and can be equipped with a supplemental loading pilot for more complex control.

Key Features:

8mm stainless steel probe with M10×1 threading

0.5-2.5mm measuring range (8mV/µm sensitivity)

Wide frequency response (0-10kHz)

IP67 environmental protection

150 bar pressure rating

Technical Specifications:

Power supply: -18 to -24VDC (±10%)

Output signal: -2 to -18VDC

Operating temperature: -40°C to +125°C

±1% linearity across full range

5m standard cable (extendable to 500m)

Performance Highlights:

±0.5µm repeatability

50g vibration resistance

MIL-spec connector for secure connections

NIST-traceable calibration available

Typical Applications:

Steam turbine shaft monitoring

Compressor rotor position measurement

Hydroelectric generator bearings

Critical pump train protection

General industrial rotating equipment

Certifications:

Complies with API 670 (4th Ed.)

Meets ISO 7919 standards

CE marked (ATEX optional)

SIL 2 capable

Installation Notes:

Requires carbon steel targets (AISI 4140 recommended)

25N·m mounting torque

Proper grounding required for optimal performance

The Rexroth HDS042-W200N-HS95-01-FW is a high-performance industrial servo drive designed for precision motion control applications in manufacturing and automation industries. Its robust design and advanced features make it an ideal choice for machine builders and system integrators seeking reliable and efficient performance.
