The X20AT6402 represents B&R's advanced analog output solution within the X20 automation system, delivering exceptional signal accuracy for demanding control applications. This versatile module provides four fully isolated channels configurable as either voltage or current outputs, making it ideal for precision process control systems.

Technical Parameters General Product Line: Fisher Whisper Noise and Cavitation Control Trims Model: Whisper NXV Trim Type: Multi-stage, cage-style, labyrinth path trim. Valve Body Compatibility: Fisher easy-e globe valve bodies (e.g., ET, EWT, ES models). Design & Performance Noise Reduction: Capable of achieving noise reductions of up to 50 dBA or more compared to a single-stage orifice, making it one of the most effective trim designs available. Cavitation Control: Eliminates cavitation damage by managing the pressure drop across multiple stages, ensuring the internal pressure at each stage remains above the fluid's vapor pressure. Pressure Staging: Utilizes dozens of individual turns and chambers to create a high number of pressure stages, dissipating energy in a controlled manner. Flow Characteristic: Inherent flow characteristic is modified linear, designed to provide stable control over the entire travel range. Pressure & Temperature Pressure Class: Available for valve bodies rated ANSI Class 150 through 2500. Temperature Rating: Suitable for the full temperature range of the compatible easy-e body, typically from -29°C to 593°C (-20°F to 1100°F), depending on body and trim materials. Sizing & Capacity Valve Size Range: Typically available for valve sizes 1 inch through 12 inches (DN 25 through DN 300). Flow Capacity (Cv): The Cv value for an NXV trim is specific to its part number and is generally lower than a single-stage trim of the same size due to the restrictive flow path. Exact Cv values are determined using Fisher sizing software. Liquid Pressure Recovery (FL): The NXV design results in a high FL factor, making it highly resistant to cavitation. Materials Trim Materials: Standard materials include 17-4PH stainless steel and 316 stainless steel. Other hardened and corrosion-resistant alloys like Alloy 20, 410 SS, 440C SS, and Stellite are available for more severe services. Cage & Component Materials: Constructed to match the process requirements and provide long-term durability under high-energy flashing or cavitating conditions. Applications High-Pressure Drop Services: Pressure reduction, let-down applications. Liquid Services: Pump minimum flow (recirculation), feedwater control, water injection, where cavitation is a primary concern. Gas & Steam Services: High-pressure steam let-down, compressor anti-surge, gas pressure reduction, where noise is the primary concern.

The FOXBORO P0800CE Industrial Control Module is a highly reliable and efficient solution designed for industrial automation and control systems. It is specifically engineered for applications requiring precise and stable performance.
