Key Specifications / Parameters Parameter Description / Value Part Number RPACKX00042 Packing Type Double PTFE V‑ring assembly Compatible Stem Diameter ⅜″ (9.5 mm) Material PTFE (TFE) V‑ring packing rings Kit Contents Packing rings, upper wiper, packing box ring, lantern ring (and an extra packing ring in kit) Application Stem sealing/packing replacement in Fisher sliding‑stem control valves Additional Notes The installation instructions note the kit “contains one extra packing ring (key 7)” which is to be discarded during assembly.

Key Specifications / Parameters Parameter Description / Value Part Number RPACKX00542 Stem Size (Nominal) 1¼ inch (1.25 in) Packing Type Single graphite ribbon + graphite filament packing Material Graphite ribbon/filament (low‑chloride, high‑temperature capable) Application Repair/overhaul of valve stem packing for sliding‑stem valves Kit Contents Includes the necessary rings: graphite filament rings, graphite ribbon rings, packing box ring, gland follower and associated hardware

Key Specifications / Parameters Parameter Description / Value Part Number RPACKX00532 Stem Size (Nominal) 1 inch (25.4 mm) Packing Type Single graphite ribbon + graphite filament packing Material Graphite ribbon/filament (low‑chloride, high temperature‑capable) Kit Contents Includes multiple rings: e.g., braided graphite rings, laminate graphite rings, packing box ring, gland follower, gland flange, gland studs/nuts (per instruction sheet) Application Repair/overhaul of valve stem packing for sliding‑stem valves Installation Note Designed for a specific boss (yoke boss) diameter and gland assembly; typically requires correct clearance, stem finish and follower torque for proper sealing Related Documentation Installation instructions available for RPACKX00532 listing rings and filler stack for 1” stem size

Key Specifications / Parameters Parameter Description / Value Part Number RPACKX00102 Stem Size (Nominal) ⅜″ (9.5 mm) Packing Type Single graphite ribbon + graphite filament packing Material Graphite ribbon/filament Included Components Graphite filament ring, graphite ribbon ring, lantern ring, packing box ring, packing follower Special Requirement Use one sacrificial zinc washer (0.004″ / 0.102 mm) beneath each graphite ribbon ring Application Valve stem sealing in sliding‑stem valves

Typical Technical Parameters Parameter Specification / Note Product Line FIELDVUE DVC6200 Assembly Model 1E9447X0112 Input Signal 4-20 mA HART or Foundation Fieldbus (Specific type defined by full order code) Supply Air Pressure 20 to 150 psi (1.4 to 10.3 bar) - Actuator Dependent Air Consumption Very low quiescent flow Enclosure Rating NEMA 4X (IP66/67) Ambient Temperature -40° to 185°F (-40° to 85°C) Travel Range Actuator Dependent. Defined by the specific actuator in the assembly. Valve Shutoff Rating Valve Dependent. Defined by the specific valve body included in the assembly. Mounting Directly on linear or rotary actuators (Pre-assembled unit)

Key Specifications / Parameters Specification Value / Description Product Series Fisher LOC 105 locking/switching valve module Function Provides switching or locking actuation in a control valve or regulator system (e.g., hold position, switch flow path) Typical Use Pneumatic control systems, regulators, pilot modules where lock/switch functionality is required Maximum Supply Pressure Around 125 psi for certain LOC 105‑labeled models (for example switching valve models) Operating Spring Range Some units show spring ranges such as 40‑90 psi for actuation control Ports / Connections Often ¼ in NPT pilot/control ports (varies by specific variant) Application Size Range Modular accessory — size depends on main valve/regulator it’s paired with Materials Standard industrial materials for valve modules (body, pilot, actuator)

Key Specifications / Parameters Product Series: CSB400 Series Pressure Reducing Regulators Model: CSB424‑IN Operating Principle: Direct‑acting, spring‑loaded regulator Body Sizes & End Connections: Multiple options including NPT, Rp (gas thread), ANSI flanged (CL 125 FF / CL 150 FF), PN‑rated, depending on model build Maximum Operating Inlet Pressure: Up to ~16 bar (232 psig) for certain builds; emergency rating ~20 bar (290 psig) for some builds Outlet Pressure Range (typical): From ~17 mbar (≈6.8 in w.c.) up to ~3.0 bar (≈43.5 psig) for standard models Operating Temperature Range: Standard −20 °C to +66 °C (−4 °F to +150 °F); Some low‐temperature versions go down to −30 °C (−22 °F) Materials: Bodies available in ductile cast iron and WCC steel; other internals include various alloys and elastomers depending on service Pressure Registration Options: Internal, external or dual registration of downstream pressure; variants include integrated monitor or slam‑shut modules for overpressure protection Typical Applications: Gas pressure reducing stations, commercial/industrial gas service, where stable downstream pressure and safety is required

Typical Technical Parameters Parameter Specification / Note Product Line Fisher Control-Scan CS400 Model CS400IN-8E Input Type Single-channel, Analog Input Input Signal 4-20 mA DC (Two-wire transmitter loop) Number of Channels 1 System Communication Proprietary Control-Scan network protocol via the CS400 baseplate. Power Supply Powered by the CS400 baseplate (typically 24 VDC). Isolation Channel-to-system isolation (typical for such modules). Operating Temperature 0 to 60 °C (32 to 140 °F) - for standard industrial environments. Mounting Plugs into a dedicated CS400 baseplate/rack.

Typical Technical Parameters Parameter Specification / Note Model Type LOC477 Valve Size Common sizes include 2 inch, 3 inch, and 4 inch (Depending on specific order code) Pressure Rating Typically Class 125 or Class 150 End Connections Flanged (Standard) Body Material Cast Iron (Standard for water and oil services), Ductile Iron, Bronze, or Cast Steel available. Trim Material Bronze or Stainless Steel Float Material Copper or Stainless Steel Operating Pressure Varies with size and body material; typically up to 250-400 psi for cast iron. Leverage Ratio Available in different ratios (e.g., 1:1, 2:1) to provide the required force for valve operation against line pressure. Application Level control in storage tanks, water supply tanks, reservoirs, and similar vessels.

Typical Technical Parameters Parameter Specification / Note Product Line FIELDVUE DVC2000 Assembly Model FV-4112 Core Instrument DVC2000 Digital Valve Controller Actuator Fisher 1061 Series Diaphragm Actuator Input Signal 4-20 mA DC, with HART 5/7 protocol Supply Air Pressure Actuator Dependent. Common range for the 1061 actuator is up to 150 psig (10.3 bar). Air Consumption (Quiescent) Typically < 0.2 SCFM (0.34 Nm³/hr) Enclosure Rating NEMA 4X (IP66) Actuator Action Spring-to-Close / Air-to-Open (Typically for FV-4112). Can often be converted to the opposite action in the field. Valve Stem Travel Actuator Dependent. The specific travel (e.g., 3/4 inch, 1.5 inch) is defined by the exact 1061 actuator model in the assembly. Mounting The assembly is designed for direct mounting onto a compatible control valve body.
