Key Parameters Category Description / Value Product Line Eaton 9SX UPS Series Type Online Double-Conversion UPS Rated Power Capacity 3000 VA / 3000 W Input • Voltage: 120 V AC • Connection: IEC connector (e.g., NEMA 5-15P) • Phase: 1-Phase Output • Voltage: 120 V AC • Connection: IEC outlets (e.g., (5) IEC 320 C13 outlets) • Phase: 1-Phase Topology Double-Conversion Online Typical Runtime Varies based on load; extended runtime available with external battery packs (EBM). Display/Interface LCD status display and control buttons. Communication USB, Serial, and optional network management card slot. Form Factor Tower

Key Parameters Category Description / Value Product Line Eaton FAZT (Fuse Switch Disconnectors) Rated Operational Current (Iₑ) 320 A (for the switch mechanism) Utilization Category AC-22B (for switching mixed resistive and inductive loads) or AC-23B (for switching motor loads) - Must be verified from datasheet. Rated Operational Voltage (Uₑ) Up to 690 V AC Rated Insulation Voltage (Uᵢ) 690 V / 1000 V Switch Function Load switching and isolation Protection Provided by external DIN-type fuses (e.g., 00 or 1 size, up to 320A) Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Screw terminals. Standards Compliance IEC/EN 60947-3

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 Motor Protection Circuit Breakers (e.g., NZM3-XV... series) Function Analog Setting Digitization Module / Motor Drive Interface Input Reads the physical position of the breaker's analog setting potentiometers. Output Digital data representing the breaker's current settings. Communication Interface Typically requires connection to a System Interface (SI) module (e.g., XV-SI) for integration into a network (e.g., Profibus, DeviceNet, Modbus-TCP). Mounting Designed to be mounted directly onto the compatible NZM3 breaker. Purpose • Setting Read-back: Allows a control system to read the actual protection settings configured on the breaker. • Condition Monitoring: Verifies that the settings have not been manually changed without the control system's knowledge. • Documentation: Provides digital documentation of protection parameters.

Key Parameters Category Description / Value Product Line Eaton DILM (Contactor) & Accessories (Timer) Compatible Contactor DILM115C Contactor Rated Operational Current (Iₑ) at AC-3 115 A (For squirrel-cage motors) Contactor Rated Operational Power at AC-3 ~ 55 kW / 75 HP at 400V 50Hz Contactor Poles 3 (Main Contacts) Contactor Coil Control Voltage DC - The specific voltage (e.g., 24V, 110V DC) must be confirmed by the order code sticker on the contactor itself. Module Type Timer Module Timer Function Specific function (e.g., On-delay, Off-delay, Star-Delta) as defined by "GC" code. Module Power Supply Derived from the main contactor coil circuit. Mounting Snap-on mounting directly onto the DILM115C contactor. Standards Compliance IEC/EN 60947-4-1

Key Parameters Category Description / Value Product Line Eaton PL (Miniature Circuit Breakers) Rated Current (Iₙ) 16 A Number of Poles Typically available in 1-Pole, 2-Pole, 3-Pole, and 4-Pole versions Tripping Characteristic D-Curve (Instantaneous trip between 10-20 x Iₙ) Rated Operational Voltage (Uₑ) 230/400 V AC Rated Insulation Voltage (Uᵢ) 500 V Breaking Capacity According to IEC/EN 60898 standard (typically 10 kA) Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Screw terminals

Key Parameters Category Description / Value Product Line Eaton PL (Miniature Circuit Breakers) Rated Current (Iₙ) 25 A Number of Poles Typically available in 1-Pole, 2-Pole, 3-Pole, and 4-Pole versions Tripping Characteristic D-Curve (Instantaneous trip between 10-20 x Iₙ) Rated Operational Voltage (Uₑ) 230/400 V AC Rated Insulation Voltage (Uᵢ) 500 V Breaking Capacity According to IEC/EN 60898 standard (typically 10 kA) Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Screw terminals

Key Parameters Category Description / Value Product Line Eaton PL (Miniature Circuit Breakers) Rated Current (Iₙ) 32 A Number of Poles 1-Pole Tripping Characteristic C-Curve (Instantaneous trip between 5-10 x Iₙ) Rated Operational Voltage (Uₑ) 230/400 V AC Rated Insulation Voltage (Uᵢ) 500 V Breaking Capacity According to IEC/EN 60898 standard (e.g., 6 kA, 10 kA). Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Screw terminals.

Key Parameters Category Description / Value Product Line Eaton PL (Miniature Circuit Breakers) Rated Current (Iₙ) 63 A Number of Poles Typically available in 1-Pole, 2-Pole, 3-Pole, and 4-Pole versions Tripping Characteristic D-Curve (Instantaneous trip between 10-20 x Iₙ) Rated Operational Voltage (Uₑ) 230/400 V AC Rated Insulation Voltage (Uᵢ) 500 V Breaking Capacity According to IEC/EN 60898 standard (typically 10 kA) Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Screw terminals

Key Parameters Category Description / Value Product Line Eaton FAZ (DIN Fuses) Rated Current (Iₙ) 6 A Fuse Characteristic Time-Delay (Slow-Blow, Type C) Rated Voltage (Uₑ) 500 V AC (as indicated by "/2" size code) Fuse Size/Dimension 10 x 38 mm (DIN 43620) Breaking Capacity High, typically 50 kA or more at 500V AC Standards Compliance IEC 60269-1, UL 248-14 (or equivalent) Fuse Type Cartridge Fuse

Key Parameters Category Description / Value Product Line Eaton FAZ (DIN Fuses) Rated Current (Iₙ) 13 A Fuse Characteristic Quick-Acting (Fast-Blow, Type D) Rated Voltage (Uₑ) 500 V AC (as indicated by "/2" size code) Fuse Size/Dimension 10 x 38 mm (DIN 43620) Breaking Capacity High, typically 50 kA or more at 500V AC Standards Compliance IEC 60269-1, UL 248-14 (or equivalent) Fuse Type Cartridge Fuse
