Technical Parameters Parameter Category Specification Details General Model EU5C-SWD-DP Form 4S, Three-Phase, 4-Wire Meter with Advanced Features ("DP") Product Line Eaton Crouse-Hinds Series / Power Xpert Metering Electrical Characteristics System Type Three-Phase, 4-Wire (3P4W - Wye) Rated Voltage 347/600V AC (Line-to-Line) Current Input Via external Current Transformers (CTs). Common secondary ratings: 5A or 1A. Frequency 50/60 Hz Measurement Capabilities Basic Parameters Volts (L-N, L-L), Amps, Frequency, Real/Reactive/Apparent Power (kW, kvar, kVA), Power Factor, Demand (kW, kVA, A) Energy Import/Export kWh, kvarh Power Quality Total Harmonic Distortion (THD) for V & I, Individual Harmonics, Min/Max/Average recordings, Sag/Swell detection. Communication Communication Ports The "DP" variant typically includes multiple ports, often an Ethernet port and a RS-485 serial port. Protocols Commonly supports Modbus TCP/IP (over Ethernet), BACnet IP (over Ethernet), and Modbus RTU (over RS-485). Display Integrated backlit LCD, often graphical. Accuracy Standard ANSI C12.20 Class 0.2 (Revenue Grade) Voltage & Current ±0.1% of Reading Power & Energy ±0.2% of Reading Physical & Environmental Mounting Hardwired installation into a dedicated meter socket within an Eaton enclosure. Operating Temperature -40°C to +70°C (-40°F to +158°F)

Technical Parameters Parameter Category Specification Details General Model DIL-SWD-32-002 DIL Series, Side-Mount, Screw Terminal, 2NO Contact Block Compatible Main Devices Eaton DIL Contactors and Relays Must be used with specific DIL series models. Contact Characteristics Number of Contacts 2 NO (Normally Open) Contact Type Screw terminal. Rated Operational Current (Ith) Typically 6 A (e.g., at 250V AC). Rated Thermal Current (Ithe) 10 A. Rated Operational Voltage (Ue) Up to 250V AC / 30V DC. Mechanical Characteristics Mounting Side-mounted onto compatible DIL contactors/relays. Electrical Durability Typically > 10 million operations. Mechanical Durability Typically > 20 million operations. Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, CE, IEC/EN 60947-5-1.

Technical Parameters Parameter Category Specification Details General Model DIL-SWD-32-001 DIL Series, Side-Mount, Screw Terminal, 1NO+1NC Contact Block Compatible Main Devices Eaton DIL Contactors and Relays Must be used with specific DIL series models. Contact Characteristics Number of Contacts 1 NO (Normally Open) + 1 NC (Normally Closed) - One Form C (Changeover) contact. Contact Type Screw terminal. Rated Operational Current (Ith) Typically 6 A (e.g., at 250V AC). Rated Thermal Current (Ithe) 10 A. Rated Operational Voltage (Ue) Up to 250V AC / 30V DC. Mechanical Characteristics Mounting Side-mounted onto compatible DIL contactors/relays. Electrical Durability Typically > 10 million operations. Mechanical Durability Typically > 20 million operations. Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, CE, IEC/EN 60947-5-1.

Technical Parameters Parameter Category Specification Details General Model DILM40-11N DILM Series, 40A, Standard Design Product Line Eaton DILM Contactors Main Contact Characteristics Rated Operational Current (Ie) 40 A (at AC-3, 400V) Rated Thermal Current (Ith) 55 A Rated Insulation Voltage (Ui) 690 V Rated Operational Voltage (Ue) Up to 690V AC Motor Power Rating (AC-3) 22 kW (30 HP) @ 400V AC Poles 3 (Main Poles) Coil Characteristics Coil Voltage 24V DC Power Consumption Approx. 8 W (DC) Pick-up Voltage Typically 80-110% of rated voltage Mechanical Characteristics Electrical Durability Typically > 1 million operations (at rated current) Mechanical Durability Typically > 10 million operations Mounting Standard 35mm DIN Rail or screw mounting Auxiliary Contacts Standard Configuration Typically 1 Normally Open (NO) auxiliary contact Expandable Yes, with additional auxiliary contact blocks Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, IEC/EN 60947-4-1

Technical Parameters Parameter Category Specification Details General Model PKE-XTU-32 Power Xpert 1000 External CT Module, 32A Compatible Meter Eaton Power Xpert 1000 (PXM, PXG series) Must be used with compatible Eaton meters. Electrical Characteristics Rated Primary Current (Ipr) 32 A Rated Secondary Current (Is) Typically 5 A (or 1A, must be verified with datasheet). System Type 3-Phase, 4-Wire (3P4W) Rated Frequency 50/60 Hz Accuracy Class Typically 0.3% or better, suitable for revenue-grade metering. Rated Insulation Voltage Typically 600V or higher. Mechanical Characteristics Mounting Designed for DIN rail mounting or panel mounting. Connection Screw terminals for both primary and secondary wiring. Standards & Compliance Safety Standards ANSI C12.xx, UL, CE, IEC 61869-2 (for Instrument Transformers)

Technical Parameters Parameter Category Specification Details General Model P5-160/V/SVB/HI10 P5 Series, 160A, Voltage, Bypass, Enclosure, Control Type Product Line Eaton P5 Soft Starter Electrical Characteristics Rated Operational Current 160 A (This is the maximum current the soft starter is designed to handle). Rated Motor Power Dependent on voltage. Example: Approx. 75 kW / 100 HP @ 400V AC. Rated Voltage The "V" indicates a standard voltage version, typically up to 500V AC / 690V AC (50/60 Hz). Control Supply Voltage Typically a separate low voltage supply (e.g., 24V DC or 110-230V AC) for the control electronics. Key Features Bypass Contactor Yes (VB) - Integrated internal bypass contactor. Enclosure The "S" likely indicates a Standard enclosure, possibly IP00 for panel mounting. Control Interface HI10 - Advanced human interface with LCD display and keypad. Starting Modes Voltage ramp, current limit. Protection Functions Overload, phase loss, current unbalance, jam, underload, excessive start time. Mechanical Characteristics Mounting Panel-mounted or chassis-mounted. Connection Screw terminals.

Technical Parameters Parameter Category Specification Details General Model EMT6-DBK EMT6 Meter Enclosure, Dark Bronze Compatible Meter Eaton Power Xpert 6000 (EMT6) Series Meters Must be used with EMT6 series meters. Enclosure Characteristics Type Surface Mount Enclosure Color DBK - Dark Bronze Material Typically high-impact, UV-resistant thermoplastic or polycarbonate. Protection Rating (IP) Typically IP40 (Protection against solid objects >1mm, no protection against water). Suitable for indoor, dry locations. Physical Characteristics Mounting Mounts on a wall or flat surface via integrated mounting holes. Transparent Cover Features a clear window allowing for full visibility of the meter's display.

Technical Parameters Parameter Category Specification Details General Model MSAA66166 Memshield 3, 63A, 3-Pole, C-Curve, 10kA Product Line Eaton Memshield 3 (MS3) Electrical Characteristics Rated Current (In) 63 A Number of Poles 3 Rated Voltage (Ue) 415V AC / 240V AC Tripping Characteristic C-Curve (Instantaneous trip: 5 to 10 x In) Rated Breaking Capacity (Icn) 10 kA (at 400V AC according to IEC 60898) Rated Frequency 50/60 Hz Mechanical Characteristics Mounting Standard 35mm DIN Rail Electrical Life Typically > 10,000 cycles Terminal Type Screw clamp terminals suitable for copper conductors. Standards & Compliance Safety Standards IEC/EN 60898-1, CE marked.

Technical Parameters Parameter Category Specification Details General Model DILM1000C-XHI11-SI DILM Series, 1000A, Electronic Coil Module, SI Terminals Product Line Eaton DILM High Performance Line Main Contact Characteristics Rated Operational Current (Ie) 1000 A (at AC-3, 600V) Rated Thermal Current (Ith) 1000 A Rated Insulation Voltage (Ui) 1000 V Rated Operational Voltage (Ue) Up to 690V AC Motor Power Rating (AC-3) 1000 HP (at 600V AC) Poles 3 (Main Poles) Coil & Control Module (-XHI11) Control Supply Voltage The "-XHI11" module is designed for a specific control voltage range. This is critical to confirm, but common versions include 24-240V AC/DC or other wide ranges. Power Consumption Significantly reduced holding power due to the electronic module. Functions Soft start/stop, Energy saving mode, Diagnostic LED. Mechanical Characteristics Terminal Type SI - Screw In terminals for main power connections. Electrical Durability High number of cycles (e.g., > 1 million at rated current). Mounting Fixed mounting. Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, IEC/EN 60947-4-1

Technical Parameters Parameter Category Specification Details General Model DILM1000C-XHI11-SA DILM Series, 1000A, Electronic Coil Module, SA Terminals Product Line Eaton DILM High Performance Line Main Contact Characteristics Rated Operational Current (Ie) 1000 A (at AC-3, 600V) Rated Thermal Current (Ith) 1000 A Rated Insulation Voltage (Ui) 1000 V Rated Operational Voltage (Ue) Up to 690V AC Motor Power Rating (AC-3) 1000 HP (at 600V AC) Poles 3 (Main Poles) Coil & Control Module (-XHI11) Control Supply Voltage The "-XHI11" module is designed for a specific control voltage range. This is critical to confirm, but common versions include a wide range like 24-240V AC/DC. The module allows low-current control. Power Consumption Significantly reduced holding power due to the electronic module. Functions Soft start/stop, Energy saving mode, Diagnostic LED. Mechanical Characteristics Terminal Type SA - Specific terminal style, commonly stud or saddle-clamp terminals for main power connections. Electrical Durability High number of cycles (e.g., > 1 million at rated current). Mounting Fixed mounting. Standards & Compliance Safety Standards UL 508, CSA C22.2 No. 14, IEC/EN 60947-4-1
