Technical Parameters Parameter Category Specification Product Model EASY410-DC-RE Product Line EASY400 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 24 V DC Power Consumption Typically 6 W (including loads) Core Processor 8-bit microcontroller User Program Memory 500 function blocks (non-volatile) Data Memory 64 flags (non-volatile) Real-Time Clock (RTC) Not available Digital Inputs 4 x Digital Inputs • 24 V DC (sinking/sourcing) Digital Outputs 2 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs Not available High-Speed Counters Not available Display & Operation No built-in display. Status is indicated by LEDs only. Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/600/800 devices (via RJ12 connectors). • PC Connection: For programming with EASY-SOFT software. Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 90 x 71.5 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY619-AC-RC Product Line EASY600 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 100-240 V AC (85-264 V AC, 50/60 Hz) Power Consumption Typically 12 W (including loads) Core Processor 32-bit microcontroller User Program Memory 1,000 function blocks (non-volatile) Data Memory 256 flags (non-volatile) Real-Time Clock (RTC) Integrated Digital Inputs 8 x Digital Inputs • 24 V DC (sinking/sourcing) • 2 of them can be used as analog inputs (0-10 V) or high-speed counters (5 kHz) Digital Outputs 6 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs 2 x Analog Inputs (shared with 2 digital inputs) • 0 - 10 V DC • Resolution: 10 bit High-Speed Counters 2 x High-Speed Counters (shared with 2 digital inputs) • Frequency: up to 5 kHz Display & Operation Integrated Color Graphic Display (RC) • TFT color screen • 8 function keys with customizable labels Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/600/800 devices (via RJ12 connectors). • PC Connection: For programming with EASY-SOFT software. Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 126 x 90 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY512-AC-RC Product Line EASY500 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 100-240 V AC (85-264 V AC, 50/60 Hz) Power Consumption Typically 10 W (including loads) Core Processor 8-bit microcontroller User Program Memory 500 function blocks (non-volatile) Data Memory 64 flags (non-volatile) Real-Time Clock (RTC) Not available on this model Digital Inputs 6 x Digital Inputs • 24 V DC (sinking/sourcing) Digital Outputs 4 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs Not available on this model. High-Speed Counters Not available on this model. Display & Operation Integrated Color Display (RC) • Basic color screen for text and status indication. • Navigation keys for operation. Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/500/600/800 devices (via RJ12 connectors). • PC Connection: For programming with EASY-SOFT software. Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 90 x 71.5 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY719-AC-RC Product Line EASY700 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 100-240 V AC (85-264 V AC, 50/60 Hz) Power Consumption Typically 15 W (including loads) Core Processor 32-bit microcontroller User Program Memory 2,000 function blocks (non-volatile) Data Memory 512 flags (non-volatile) Real-Time Clock (RTC) Integrated (buffered) Digital Inputs 12 x Digital Inputs • 24 V DC (sinking/sourcing) • 4 of them can be used as analog inputs (0-10 V, 0/4-20 mA) or high-speed counters (5 kHz) Digital Outputs 8 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs 4 x Analog Inputs (shared with 4 digital inputs) • Configurable: 0 - 10 V, 0/4 - 20 mA • Resolution: 10 bit High-Speed Counters 4 x High-Speed Counters (shared with 4 digital inputs) • Frequency: up to 5 kHz Display & Operation Integrated Color Graphic Display (RC) • High-resolution TFT color screen • 8 function keys with customizable labels Programming Interface Integrated EASY-PC interface (via RJ12 connector) & USB port Communication • EASY-LINK: For networking up to 12 EASY devices. • Ethernet (optional module): For integration into plant networks and remote access. • PC Connection: Via USB or RJ12. Programming Software Eaton EASY-SOFT (Version 7 or higher recommended for full functionality) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 126 x 90 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY412-AC-R Product Line EASY400 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 100-240 V AC (85-264 V AC, 50/60 Hz) Power Consumption Typically 8 W (including loads) Core Processor 8-bit microcontroller User Program Memory 500 function blocks (non-volatile) Data Memory 64 flags (non-volatile) Real-Time Clock (RTC) Not available on this model Digital Inputs 6 x Digital Inputs • 24 V DC (sinking/sourcing) Digital Outputs 4 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) • Note: The total current for all outputs combined must not exceed 16 A. Analog Inputs Not available on this model. High-Speed Counters Not available on this model. Display & Operation No built-in display. Status indicated by LEDs. Programming and monitoring require a PC. Programming Interface Integrated EASY-PC interface (via RJ12 connector) Communication • EASY-LINK: For networking up to 12 EASY400/600/800 devices (via RJ12 connectors) • PC Connection: For programming with EASY-SOFT software Programming Software Eaton EASY-SOFT (Version 6 or higher recommended) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 90 x 71.5 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY719-DC-RC Product Line EASY700 Device Type Programmable Logic Relay (PLR) / Smart Relay Supply Voltage 24 V DC (19.2 - 28.8 V DC) Power Consumption Typically 15 W (including loads) Core Processor 32-bit microcontroller User Program Memory 2,000 function blocks (non-volatile) Data Memory 512 flags (non-volatile) Real-Time Clock (RTC) Integrated (buffered) Digital Inputs 12 x Digital Inputs • 24 V DC (sinking/sourcing) • 4 of them can be used as analog inputs (0-10 V, 0/4-20 mA) or high-speed counters (5 kHz) Digital Outputs 8 x Relay Outputs • Switching Capacity: 250 V AC / 30 V DC Max. • 8 A (at 250 V AC Resistive) • 5 A (at 250 V AC Inductive, cos φ=0.4) Analog Inputs 4 x Analog Inputs (shared with 4 digital inputs) • Configurable: 0 - 10 V, 0/4 - 20 mA • Resolution: 10 bit High-Speed Counters 4 x High-Speed Counters (shared with 4 digital inputs) • Frequency: up to 5 kHz Display & Operation Integrated Color Graphic Display (RC) • High-resolution TFT color screen • 8 function keys with customizable labels Programming Interface Integrated EASY-PC interface (via RJ12 connector) & USB port Communication • EASY-LINK: For networking up to 12 EASY devices. • Ethernet (optional module): For integration into plant networks and remote access. • PC Connection: Via USB or RJ12. Programming Software Eaton EASY-SOFT (Version 7 or higher recommended for full functionality) Protection Rating Front panel: IP65 (when mounted) Housing: IP20 Mounting DIN rail mounting (35 mm) Ambient Temperature -25 °C to +55 °C (Operation) -40 °C to +70 °C (Storage) Dimensions (H x W x D) Approx. 126 x 90 x 64 mm

Technical Parameters Parameter Category Specification Product Model EASY-USB-CAB Product Name USB Programming Cable Cable Function Programming, Online Monitoring, and Communication Compatible Devices All Eaton EASY series PLRs (EASY400, EASY500, EASY600, EASY700, EASY800) PC Connection USB Type-A connector EASY Controller Connection 6-pin RJ12 modular connector Cable Length Approximately 2.5 meters Integrated Electronics Yes (contains a USB to serial converter) Supported Operating Systems Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10, Windows 11 (Requires driver installation, usually provided with EASY-SOFT software) Primary Use • Downloading programs to the EASY controller • Uploading programs from the EASY controller • Online debugging and monitoring • Configuring EASY-LINK networks via software LED Indicator Typically includes a status LED to indicate communication activity.

Technical ParametersProduct Name: PC Programming Cable for easy500/700 Catalog Number: EASY-PC-CAB Interface Type: RS-232 (PC to controller) Compatible Devices: Eaton easy500 series / easy700 series Function: Programming, monitoring, and configuration Length: Approx. 7 in (≈178 mm) Width: Approx. 5.5 in (≈140 mm) Height: Approx. 1 in (≈25 mm) Weight: Approx. 0.2 lb (≈0.09 kg) Warranty: 1 year Certifications: UL / cUL

Technical Parameters Power Supply Voltage: 24 V DC Digital Inputs: 12 inputs at 24 V DC Relay Outputs: 6 relay outputs Relay Output Rating: 8 A thermal per relay Rated Operational Voltage (Relay Contacts): Up to 250 V AC Heat Dissipation: Approximately 4 W Protection & Isolation Short-Circuit Protection: Requires external protection (e.g., B16 circuit breaker or 8 A slow-blow fuse) Isolation: Safe isolation between input circuits and relay contacts, compliant with industrial standards Wiring & Connections Wiring Capacity: Solid wire: 0.2–4.0 mm² (AWG 22–12) Flexible wire: 0.2–2.5 mm² Connection Method: Screw terminals Communication: easyLINK expansion interface Mechanical Specifications Mounting Type: 35 mm DIN rail Dimensions: Width: approx. 3.5 in Height: approx. 3 in Depth: approx. 4.5 in Weight: approx. 0.39 kg (0.86 lb) Environmental Specifications Operating Temperature: –25 °C to +55 °C Standards & Certifications: CE, UL, CSA, EN industrial control standards

Technical Parameters Parameter Specification Brand Eaton Product Model NZMN3-A450 Standard IEC 60947-2 Type Miniature Circuit Breaker (MCB) Number of Poles 3 Poles (3P) Rated Current (Iₙ) 50 A Tripping Characteristic / Curve Type C (Instantaneous trip: 5 to 10 x Iₙ) Rated Operational Voltage (Uₑ) 400 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 500 V AC Rated Impulse Withstand Voltage (Uᵢₘₚ) 6 kV Breaking Capacity (I꜀ᵤ) 10 kA (at 400V AC) Electrical Durability 10,000 cycles Mechanical Durability 20,000 cycles Terminal Capacity - Top & Bottom Terminals Solid: 50 mm² Stranded: 35 mm² Fine-stranded: 25 mm² Terminal Torque 3.0 N·m (Maximum) Mounting 35 mm DIN Rail (EN 60715) Degree of Protection IP20 (when installed in an enclosure) Ambient Temperature -25 °C to +60 °C (for reference, per standard) Approvals / Certifications CE, CCC, IEC 60947-2
