Technical Parameters Category Specification Model M22-DL-B Product Type 2-Wire AC Inductive Proximity Sensor Housing Thread M22 x 1 Sensing Distance 5 mm (Nominal) Output Type 2-wire AC Supply Voltage 20-253V AC, 50/60 Hz Rated Current Typically 5-200 mA (depending on model) Leakage Current Typically < 1.8 mA Connection Type Fixed Cable Housing Material Nickel-Plated Brass Target Material Ferrous Metals (e.g., Steel) IP Rating IP67 (Dust-tight and protected against temporary immersion)

Technical Parameters Category Specification Model A22-QDDL-11/10 Product Type Illuminated 2-Position Selector Switch Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Switch Positions 2 Lens Color (Position 1 / Position 2) Red / Green Illumination Incandescent Bulbs (one for each position) Contact Block Not Included. One or more separate contact blocks (e.g., A22-C series) must be purchased and stacked to provide the required switching logic. Voltage for Lamps Depends on the specific bulbs installed (e.g., 24V, 110V, 220V). Must be specified separately for each lamp.

Technical Parameters Category Specification Model A22-RWK1V Product Type Illuminated Pushbutton (Maintained/Latching Action) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Rectangular, Maintained (Latching) Button Color White (Actuator) Lens Color Green (Illumination) Illumination Incandescent Bulb Contact Block Not Included. This is only the operator (button and lamp assembly). A separate contact block (e.g., A22-C series) must be purchased. Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 24V, 48V, 110V, 220V). Must be specified separately.

Technical Parameters Category Specification Model A22-IGE1M Product Type Illuminated Pushbutton (Momentary Action) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Round, Momentary Button Color Yellow (Actuator) Lens Color Green (Illumination) Illumination Incandescent Bulb Contact Block Not Included. This is only the operator (button and lamp assembly). A separate contact block (e.g., A22-C) must be purchased. Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 12V, 24V, 48V, 110V, 220V). Must be specified separately.

Technical Parameters Category Specification Model A22-RPV Product Type Illuminated Pushbutton (Maintained/Latching Action) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Rectangular, Maintained (Latching) Lens Color Green Illumination Incandescent Bulb Contact Block Not Included. This is only the operator (button and lamp assembly). A separate contact block (e.g., A22-C series) must be purchased. Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 24V, 48V, 110V, 220V). Must be specified separately.

Technical Parameters Category Specification Model A22-I1M Product Type Illuminated Pushbutton (Momentary Action) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Round, Momentary Lens Color Red Illumination Incandescent Bulb Contact Block Not Included. This is only the operator (button and lamp assembly). A separate contact block (e.g., A22-C) must be purchased. Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 12V, 24V, 48V, 100V, 110V, 120V, 200V, 220V, 240V). Must be specified separately.

Technical Parameters Category Specification Model A22-RLT-GE Product Type Illuminated Pushbutton (Maintained/Latching Action) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Rectangular, Maintained (Latching) Button Color Yellow (Actuator) Lens Color Red (Illumination) Illumination Incandescent Bulb Contact Block Not Included. A separate contact block (e.g., A22-C series) must be purchased. Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 24V, 48V, 110V, 220V). Must be specified separately.

Parameter Specification Product Model A22-I3M Product Line Eaton A22 Series Product Type Indicator Light Lens Color Green Illumination Type Incandescent or LED (module dependent) Rated Voltage e.g., 24 V DC, 120 V AC (depends on lamp/LED module) Power Consumption 1.2–2 W (typical for LED) Mounting Hole Diameter 22.5 mm Protection Rating IP65 (front panel) Lens Material Polycarbonate Housing Material Thermoplastic (e.g., PA66) Terminal Type Screw terminals Operating Temperature -25°C to 55°C

Parameter Specification Product Model A22-RWK3R Product Line Eaton A22 Series Actuator Type Mushroom head, red Contact Configuration 1 NC (Normally Closed) (typical for emergency stop) Operation Type Maintained (latching) with twist-to-release reset Rated Operational Current 5 A at 250 V AC Illumination Voltage e.g., 24 V DC (depends on variant) Mounting Hole Diameter 22.5 mm Protection Rating IP65 (front panel) Terminal Type Screw terminals Operating Temperature -25°C to 55°C Safety Standards IEC 60947-5-1, UL 508

Parameter Specification Product Model A22-RWK1V Product Line Eaton A22 Series Actuator Type Mushroom head, red Contact Configuration 1 NO (Normally Open) (typical for "1V" variant) Rated Operational Current 5 A at 250 V AC Illumination Voltage e.g., 24 V DC (depends on "1V" specification) Mounting Hole Diameter 22.5 mm Protection Rating IP65 (front panel) Terminal Type Screw terminals Operating Temperature -25°C to 55°C Mechanical Life >1 million operations
