Model Number P0916JR0C Product Line Foxboro I/A Series Module Type Redundant, Hot-Swappable AC/DC Power Supply Module Key Feature Provides N+1 redundant, fault-tolerant power for high-availability I/A Series nodes. Input Specifications Input Voltage Likely a wide range, such as 90-264 VAC automatically sensed, or a specific voltage like 120/240 VAC. The "J" code defines this. Input Frequency 47 - 63 Hz (Standard for 50/60 Hz systems). Power Factor Correction (PFC) Active PFC is highly probable for a module of this capacity. Output Specifications Output Voltages Provides multiple isolated DC outputs for the system backplane: • +5.1 VDC • +15.2 VDC • -15.2 VDC • +24.8 VDC (for field instrument power) Total Output Power High Capacity (Estimated 1600W or higher, based on the "16" in the code). This is suitable for large racks. Redundancy True N+1 Redundancy supported. Modules operate in a current-sharing, load-sharing mode. Protections Comprehensive: Over-voltage (OVP), Over-current (OCP), Over-temperature (OTP), and Short-circuit protection. Physical & Operational Mounting Slides into a dedicated bay in a redundant power chassis (e.g., PSS31). Hot-Swappable Yes. Can be inserted or removed under full load. Cooling Internal fan(s) for forced-air cooling. Status Indicators (LEDs) Comprehensive LEDs for AC OK, DC OK, Load Share, Unit Fail, and Replace Indicator. Communication May include a serial communication link for reporting status and alarms to the system. Environmental Operating Temperature 0°C to +60°C (with derating above a certain ambient temperature). Efficiency High efficiency, typically > 85% to reduce heat generation.

Model Number P0903ZN Product Line Foxboro I/A Series Module Type Power Supply Module (PSU) Key Function Provides regulated DC power to all other modules (CPs, FBMs, IDPs, etc.) in an I/A Series rack. Input Specifications Input Voltage 85 - 264 VAC (Universal input, compatible with standard 120VAC and 240VAC networks). The "N" in the model code typically denotes AC input. Input Frequency 47 - 63 Hz (Compatible with both 50Hz and 60Hz power grids). Inrush Current Limit Yes, to prevent tripping circuit breakers during power-up. Output Specifications Output Voltages Provides the standard DC voltages required by the I/A Series backplane: • +5 VDC (for digital logic circuits) • ±15 VDC and/or +24 VDC (for analog circuits and field I/O power) Total Output Power Approximately 300 Watts (The "03" in the model code often indicates this power level). The exact rating must be verified. Efficiency Typically > 80%. Protections Overload (current limit), over-voltage, and over-temperature protection. Physical & Environmental Mounting Installs into a dedicated slot in a Foxboro PSS (Power Supply System) rack. Hot-Swappable Yes. In a redundant configuration, it can be replaced without powering down the entire system. Operating Temperature 0°C to +60°C (standard industrial range). Status Indicators (LEDs) Includes LED indicators for Power Good (PWR OK), Fault (FAIL), and Load Sharing status. Safety & Compliance Safety Standards Complies with UL, cUL, CE, and other international safety standards. EMC Immunity Designed to meet electromagnetic compatibility requirements for industrial environments.

Product Type Smart Electronic Valve Positioner Brand / Series Foxboro ECKARDT SRD900 Series Supply Air Pressure Typically 1.4 - 7 bar (20 - 100 psi) Output Action Single-acting (as per code "E") Ambient Temperature Standard: -30°C to +80°C (-22°F to +176°F) Enclosure & Protection Housing Material Aluminum (typical) Ingress Protection (IP) IP66/67 (NEMA 4X equivalent), protected against powerful water jets and temporary immersion. Electrical Input Signal & Wiring 4-20 mA DC, 2-wire system (as per code "B"). The device is powered by the same 4-20 mA loop. Load Resistance Typically up to 850 Ohms at 20 mA (depending on air supply pressure). Intrinsic Safety Available options for Ex ia IIC T6 Ga (must be specified in order code). Connection Cable gland, M20 x 1.5 (as per code "Z"). Mechanical & Pneumatic Mounting Direct mounting per VDI/VDE 3845 standard (as per code "D"). Adapter kits available for other standards. Travel Sensing Mechanically coupled to the valve stem; range defined by the "SG6" code. Air Consumption Very low (in steady state, typically < 0.01 Nl/min). Flow Capacity (Cv) High, allowing for fast valve stroking. Performance & Communication Accuracy High, typically better than ±0.5% of span. Hysteresis Very low, typically < 0.1%. Communication Integrated HART® protocol. This allows for digital communication for configuration, calibration, and diagnostics using a HART communicator or asset management software. This is a standard feature in smart positioners like the SRD960.

Model Number IDP10-A22821C-M1V Product Line Foxboro I/A Series® Module Type Single-Channel, Isolated Analog Input Conditioner General Description A microprocessor-based, isolated signal conditioning module for the I/A Series DCS. It provides a single channel of analog input signal conditioning with high isolation. Input Specifications Supported Input Signals • 4 to 20 mA DC (2-wire or 4-wire transmitter) • 0 to 20 mA DC • 0 to 10 V DC • Potentiometer (Ohms) Input Impedance • Current Inputs: 50 Ohms (nominal) • Voltage Inputs: > 1 MΩ Burnout Protection User-selectable via software: • Up-scale (e.g., 22 mA) • Down-scale (e.g., 3.8 mA) • Off Isolation Channel-to-Channel: Not applicable (single channel). Channel-to-System (Field-to-Logic): 1500 VAC RMS continuous. This is a key safety feature. Output Specifications Output to System A digital value representing the input signal, communicated over the FBI bus to the host controller. Resolution Typically 16-bit or higher, ensuring high measurement accuracy. Refresh Rate Dependent on the FBI bus cycle time and system configuration. Power Supply Operating Voltage Powered by the +5V and ±15V supplies from the PSS baseplate. Loop Power (for 2-wire transmitters) Typically 24 VDC nominal, with limited current capacity (e.g., ~30 mA). Environmental & Physical Operating Temperature -40°C to +70°C (-40°F to +158°F) Storage Temperature -40°C to +85°C Relative Humidity 0 to 95% (non-condensing) Mounting Installs into a dedicated Foxboro PSS series baseplate (e.g., PSS11, PSS21, PSS31). Status Indicators (LEDs) Typically includes LEDs for Power (PWR) and Fault (FLT) status. Standards & Compliance EMC Immunity Designed to meet industrial standards for immunity to Electrostatic Discharge (ESD), Radiated RF fields, and Electrical Fast Transients (EFT).

Detection Principle Photoionization Detection (PID) Measurement Range 0-1 ppm to 0-10,000 ppm (selectable ranges, e.g., 0-10/100/1000 ppm) UV Lamp Energy Standard 10.6 eV (other options: 11.7 eV) Accuracy ±2% of reading or ±1% of full scale (whichever is greater) Response Time (T90) Typically < 3 seconds Sample Method Diffusion or pumped (integrated sample pump) Output Signals - Analog: 4-20 mA DC, isolated - Alarms: 2+ SPDT relay outputs Power Supply 24 V DC (18-30 V DC range) Display Backlit LCD (concentration, status, alarms) Enclosure Rating IP66/IP67 (dust-tight, water-resistant) Operating Temperature -20°C to +50°C Calibration Field-configurable with standard calibration gases Safety Certifications ATEX, IECEx, FM (Zone 1/Division 1 hazardous areas)

Model Code B-FXSUN-XROHS P0915FU Input Signal Type: Frequency / Tachometer Waveform: Sine Wave or Square Wave Amplitude Range: 200 mV RMS to 60 V RMS (typical) Frequency Range: 0.5 Hz to 12,000 Hz (12 kHz) Output Signal Type: 4-20 mA DC, 2-wire Load: Maximum 600 Ω (at 24V DC supply) Characteristic: Linear with input frequency. Power Supply Voltage Range: 20-30 V DC Power Consumption: Typically < 5 W Isolation Rating: 1500 V AC (between Input, Output, and Power Supply) Accuracy Typical: ±0.1% of span Response Time Configurable: Typically adjustable from 50 ms to 5.0 seconds. Safety Certifications Intrinsic Safety: Certified for Class I, Division 1, Groups A, B, C, D; Zone 0 by agencies such as FM, CSA, ATEX, and IECEx. Environmental Compliance RoHS: Compliant with the Restriction of Hazardous Substances directive. Operating Temperature -20°C to +70°C Mounting Standard 35 mm DIN Rail

Model Foxboro P0971WV DNBT Type Pressure Transmitter (Gauge/Absolute) Measurement Range 0-3000 psi (e.g., "71" may indicate 0-3000 psi range) Output Signal 4-20 mA DC with HART® Protocol Accuracy ±0.065% of span (typical for 823 series) Power Supply 10.5-42 V DC (loop-powered) Process Connection 1/2" NPT Female or flanged Wetted Materials Diaphragm: 316L Stainless Steel or Hastelloy; Seals: Viton® or PTFE Housing Rating NEMA 4X (IP66) Ambient Temperature -40°C to +85°C (-40°F to +185°F) Process Temperature -40°C to +120°C (-40°F to +248°F) Protocol HART® 7 Adjustable Turndown Up to 100:1 Certifications ATEX, IECEx, SIL 2/3, DNBT (e.g., non-incendive or DIN rail) Mounting DIN rail or direct mounting (as per "DNBT" suffix)

Model Foxboro P0916FL Type Gauge Pressure Transmitter Measurement Range 0-1000 psi (e.g., "16" may indicate 0-1000 psi range) Output Signal 4-20 mA DC with HART® Protocol Accuracy ±0.065% of span (typical for 823 series) Power Supply 10.5-42 V DC (loop-powered) Process Connection 1/2" NPT Female Wetted Materials Diaphragm: 316L Stainless Steel; Seals: Viton® (FKM) Housing Rating NEMA 4X (IP66) Ambient Temperature -40°C to +85°C (-40°F to +185°F) Process Temperature -40°C to +120°C (-40°F to +248°F) Protocol HART® 7 Adjustable Turndown Up to 100:1 Stability ±0.1% of URL per year Certifications ATEX, IECEx, SIL 2/3 (depending on configuration)

Model Foxboro ICP10-T2001E-M2L1A3T Type Pressure Transmitter (Gauge/Absolute) Measurement Range 0-200 psi (e.g., "T200" may indicate 0-200 psi range) Output Signal 4-20 mA DC with HART® Protocol Accuracy ±0.25% of span (typical for ICP10 series) Power Supply 12-42 V DC (loop-powered) Process Connection 1/2" NPT Female (standard) Wetted Materials 316L Stainless Steel diaphragm and body Housing Rating NEMA 4X (IP66) Ambient Temperature -40°C to +85°C (-40°F to +185°F) Process Temperature -40°C to +120°C (-40°F to +248°F) Protocol HART® 7 Adjustable Turndown Up to 10:1 Certifications CE, RoHS (may vary by region) Electrical Connection 1/2" NPT conduit (as indicated by suffix)

Model Foxboro IMT25-IEBTB10N-B Type Multi-Variable Pressure Transmitter (DP, Static Pressure, Temperature) Measurement Range Differential Pressure (DP): 0-10 inH₂O (e.g., "10N" indicates 10 inH₂O span) Static Pressure: Up to 3600 psi (dependent on model variant) Temperature: Integrated RTD or via external sensor Output Signal 4-20 mA DC with HART® or FOUNDATION™ Fieldbus digital protocol Accuracy DP: ±0.04% of span; Static Pressure: ±0.1% of URL; Flow: ±0.5% of rate (typical) Power Supply 10.5-42 V DC (loop-powered for HART); 9-32 V DC (Fieldbus) Process Connection 1/2" NPT or flanged (e.g., 1/4" NPT for HP/LP sides) Wetted Materials Hastelloy C-276 diaphragm and seals (standard for corrosive environments) Housing Rating NEMA 4X (IP66) Ambient Temperature -40°C to +85°C (-40°F to +185°F) Process Temperature -40°C to +120°C (-40°F to +248°F) Protocol HART® 7 or FOUNDATION™ Fieldbus Adjustable Turndown Up to 100:1 Certifications SIL 2/3, ATEX, IECEx, CE Special Features Integrated flow computation, diagnostics, temperature compensation
