Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM170C XTCE170GC Rated Operational Current (Ie) 170 A at AC-3, 400V Thermal Current (Ith) 170 A Poles (Main Circuit) 3 (Normally Open) Auxiliary Contacts Typically 1 NO (Normally Open) - Fixed (configurable with additional blocks) Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage DC operating coil (Specific voltage defined by the XTCE170GC suffix). Utilization Categories AC-3: Squirrel cage motors: Starting, switching off during running AC-1: Non-inductive or slightly inductive loads Motor Rating (at 400V AC) 75 kW / 100 HP Mechanical Life ~ 5-10 million operations Electrical Life (AC-3) ~ 0.5-1 million operations Mounting Screw mounting (due to size and weight) Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Terminal Type Screw Clamp

HDSS FUS 2P3W 240V 30A N3R

The Mitsubishi MR-J4-22B is a high-performance AC Servo Amplifier designed to provide precise and efficient control of Mitsubishi’s servo motors. It is part of the MR-J4 Series, which offers advanced control features, fast response time, and enhanced energy efficiency. This amplifier is used in high-precision applications such as robotics, CNC machinery, and automated systems requiring smooth, high-torque, and high-speed motion control
