ABB 500A DC Power System

Current Rating: 500A DC

Voltage: Configurable (e.g., 24/48/110V DC)

Efficiency: >95%

Protections: Overload, Short-circuit, Overtemperature

Cooling: Forced Air

Compliance: IEC/UL Certified

Emerson EV2000-2000P UPS

Capacity: 2kVA/2kW

Type: Online Double Conversion

Input: 160-276V AC, 50/60Hz

Output: 220/230/240V AC Pure Sine Wave

Efficiency: >90%

Battery: Built-in Lead-Acid (External Extendable)

Features: Zero Transfer Time, USB/RS-232 Monitoring

Emerson UNI240311KW UPS Specifications:

Model: UNI240311KW

Type: 3-Phase Online UPS

Capacity: 240kVA / 240kW (1:1)

Input/Output: 380-415V AC, 50/60Hz

Efficiency: >96% (ECO mode)

Topology: Double Conversion

Battery: Lead-acid (Li-ion optional)

Communication: SNMP, Modbus, RS-232

Protection: Surge, overload, short-circuit

The Emerson LibertyNXL500K is a 500KVA UPS with:
3-phase 380/400/415Vac input (228-478Vac range), 50/60Hz ±5%
IGBT rectification for ≥0.99 power factor, ≤3% THDi
3-phase 380/400/415Vac output, 0.9 power factor
125% overload for 10min, 95.5% full-load efficiency
IP20 protection, 0-40℃ operation
RS485 interface for remote monitoring.

The Emerson TD2000-4T1320P is a general-purpose inverter with:
3-phase 380V/50-60Hz input (±15% voltage, ±5% frequency tolerance)
0-380V/0-99.99Hz output
150% overload for 2min, 180% for 10s
0.1% speed accuracy with PG
-10℃~+40℃ operation (derate above 40℃)
IP20 protection, wall-mounted design.

The Emerson NE300-4T0185G/0220PB is an inverter with:
- 3-phase 380-440V/50-60Hz input (304-456V range)
- G-type: 150% overload for 1min, 180% for 20s; P-type: 120%/1min, 150%/1s
- Control modes: VC (with PG), SVC (without PG), V/F
- Starting torque: 150% at 0.5Hz (SVC), 1.5Hz (V/F)
- Speed range: 1:100 (SVC), 1:50 (V/F)
- Frequency: 0.00-550.0Hz
- IP20 protection, -40°C~+70°C storage temp.

The Emerson GM150CY/150A is a medium - voltage converter. It has a power rating of 10 – 24 MVA (IGCT). For output, it offers 3 - phase AC 3.3 kV (IGCT Water; Tandem configuration: Water 2 x 3.3 kV). The input voltage operates at 50 / 60 Hz ± 3%, with an output frequency range of 0 – 250 Hz. Protection classes vary: Air - cooled models are IP22 / IP42, while Water - cooled ones are IP43 / IP54. It can reach a maximum speed of 4800 rpm and handle up to 18 MW of power.

The Emerson G100AY is a high-voltage inverter with 6kV/10kV (+15% - 45%) input, 50Hz±10% frequency. It offers 2x overload capacity, high low-speed torque, 100% PWM rectification, regenerative power matching output, 200% braking torque, and 0.99 power factor.

The Emerson SP6401 is a Unidrive SP series VFD. It features:
3-phase 380VAC input, 0~380VAC output
0~3000Hz open-loop/0~40000rpm closed-loop speed control
150% overload for 60s (heavy load)
0.01% control accuracy, 0.001Hz resolution
16kHz carrier frequency, 500kHz encoder response
Built-in EMC filter & Modbus RTU (115200bps)
IP54 protection (reference only)

The Emerson MP210A4R is a DC drive with 208-480VAC 3-phase input and 210A output. It offers 60hp at 230VAC and 125hp at 460VAC, supporting regenerative braking with forced air cooling. Operating at 0℃-55℃, it has standard RS485 and optional CANopen/DeviceNet/Ethernet interfaces. Sized 17.5×11.5×9.9 inches (29 lbs), it suits industrial motor control applications.
