IS4225 Proximity Sensor - Product Brief
Core Description:
The IS4225 is a rugged 2.5mm range inductive sensor with PNP NO output, designed for precise metal object detection in industrial automation.

Key Features:
✔ Reliable Detection

±0.02mm repeatability

500Hz response speed

LED operation indicator

✔ Industrial Durability

Nickel-plated brass housing

IP67 protection

-25°C to +70°C operation

✔ Easy Integration

M12 threaded mounting

Short-circuit protection

Direct PLC compatibility

Typical Applications:
• Machine tool limit switches
• Automated assembly lines
• Material handling systems

Certifications:
CE, RoHS, EN 60947-5-2

Model Options:

NPN output version available

ATEX certified variant

Technical Advantages:
→ 5M+ operation cycles
→ EMI/RFI immune design
→ 36-month warranty

CBL-500-300-S00 Industrial Cable Assembly - Product Brief
Core Description:
The CBL-500-300-S00 is a 5-meter shielded cable assembly designed for industrial sensor connectivity. Featuring M12 male to open-wire ends, it ensures reliable signal transmission in demanding automation environments.

Key Features:
✔ Robust Construction

4-core PUR-jacketed cable (6.5mm OD)

IP67-rated M12 connector

-40°C to +90°C operating range

✔ Electrical Performance

300V AC/DC rating

3A current capacity per conductor

EMI-shielded (braided + drain wire)

✔ Durability

5M+ flex cycles (40mm radius)

Oil/chemical resistant

UL/CSA FT1 flame rated

Typical Applications:
• Robotic arm wiring
• PLC sensor networks
• Motor encoder connections
• Factory automation systems

Certifications:
UL, CSA, CE, RoHS

Model Options:

S01: M12 female connectors

S10: Extended temp (-60°C to +105°C)

Technical Advantages:
→ 360° shielding for noise immunity
→ Torsion-resistant design
→ 24-month warranty

Word Count: 98 (adjustable)

HPMH115S0-XXX Pressure Sensor - Product Brief
Core Description:
The HPMH115S0-XXX is a high-precision MEMS pressure sensor offering ±0.5% FS accuracy for industrial applications. Customizable pressure ranges (XXX = 015/050/100 psi) and dual analog/digital outputs ensure flexible integration.

Key Features:
✔ Precision Measurement

0-115 psi range (customizable)

<1ms response time

Temperature compensated

✔ Robust Design

Anodized aluminum housing

IP65 protection

-40°C to +125°C operation

✔ Output Options

0.5-4.5V analog

I²C/SPI digital (selectable)

Typical Applications:
• Pneumatic system control
• HVAC pressure monitoring
• Industrial gas flow measurement
• Energy management

Certifications:
CE, RoHS, EN 61298-1

Model Options:

S1: IP67 version

S2: 4-20mA output

S3: Media-isolated

Technical Advantages:
→ 5V DC powered
→ EMI/RFI shielded
→ 24-month warranty

Q7800A-1005 Load Cell - Product Brief
Core Description:
The Q7800A-1005 is a precision 1005 lb (5000N) capacity load cell designed for industrial force measurement applications. With ±0.25% FS accuracy and 2.0mV/V output, it delivers reliable performance in demanding environments.

Key Features:
✔ High-Accuracy Measurement

<0.1% nonlinearity

<0.05% creep/30min

150% safe overload

✔ Robust Construction

Alloy steel material

IP67 protection

-20°C to +70°C operation

✔ Easy Integration

80×80mm platform

4x M8 mounting holes

350Ω bridge resistance

Typical Applications:
• Industrial weighing systems
• Force testing machines
• Process control equipment
• Automation quality control

Certifications:
CE, RoHS, OIML R60 compliant

Model Options:

0505: 500 lb capacity

2010: 2000 lb capacity

SS: Stainless steel version

Technical Advantages:
→ Hermetically sealed construction
→ Temperature compensated
→ 36-month warranty

N6603SR-W3-103 Rotary Encoder - Product Brief
Core Description:
The N6603SR-W3-103 is a high-precision incremental encoder with 1024 PPR resolution, designed for industrial motion control applications. Its rugged aluminum housing and IP65 protection ensure reliable position/speed feedback in harsh environments.

Key Features:
✔ Precision Measurement

±0.1° accuracy

6000 RPM max speed

A/B/Z-phase TTL output

✔ Robust Design

6mm solid shaft (keyway optional)

IP65-rated against dust/water jets

-20°C to +85°C operation

✔ Easy Integration

5V/12-24V DC versions

Push-pull output (30mA)

Reverse polarity protection

Typical Applications:
• CNC machine tools
• Robotic arm positioning
• Servo motor control
• Automated packaging lines

Certifications:
CE, RoHS, EN 61000-6-2/6-4

Model Options:

HR-W3-103: Hollow shaft version

W5-103: IP67 protection

Technical Advantages:
→ 50+ million bearing cycles
→ Shock/vibration resistant
→ Custom resolutions available

40PC Pressure Sensor - Product Brief
Core Description:
The 40PC is a compact, high-performance gauge pressure sensor designed for industrial and automotive applications. With ±1% FS accuracy and 0.5-4.5V ratiometric output, it delivers reliable pressure measurement for air and non-corrosive gases.

Key Features:
✔ Precision Measurement

0-100 psi standard range (up to 500 psi optional)

<1ms response time

Temperature compensated

✔ Rugged Design

Thermoplastic housing

IP54 protection

-40°C to +125°C operation

✔ Easy Integration

Barbed or 1/8" NPT port options

5V DC powered

Reverse polarity protection

Typical Applications:
• Automotive manifold pressure
• HVAC system monitoring
• Pneumatic control systems
• Medical ventilation devices

Certifications:
RoHS, REACH, AEC-Q100 (automotive)

Model Options:

40PC015G: 15 psi range

40PC500G: High-pressure version

HF-1000 High-Frequency Vibration Sensor - Product Brief
Core Description:
The HF-1000 is an industrial-grade vibration sensor designed for predictive maintenance of critical machinery. With a 5Hz-10kHz frequency range and ±50g measurement capability, it detects early-stage bearing faults and mechanical wear in rotating equipment.

Key Features:
✔ Precision Monitoring

100mV/g sensitivity (±5%)

0.001g RMS resolution

192kHz high-speed sampling

✔ Rugged Design

Stainless steel 316 housing

IP67 protection (dust/waterproof)

-40°C to +120°C operation

✔ Easy Integration

IEPE output (18-30V DC powered)

M6 threaded mounting

EMI/RFI shielded

Typical Applications:
• Motor/gearbox condition monitoring
• Pump and compressor diagnostics
• Wind turbine vibration analysis
• Paper mill roll balancing

Certifications:
CE, RoHS, ISO 10816 compliant

Model Options:

HF-1000-EX: ATEX hazardous area version

HF-1000-T: Triaxial vibration measurement

Technical Advantages:
→ Laser-welded hermetic sealing
→ 5000g shock survival rating
→ NIST-traceable calibration

T9275B4020 Industrial Sensor - Product Brief
Core Description:
The T9275B4020 is a high-performance dual-parameter sensor that simultaneously monitors pressure (0-40 bar) and temperature (-40°C to +125°C) in industrial systems. Designed for harsh environments, it delivers ±0.25% pressure accuracy and ±0.5°C temperature precision with a rapid <50ms response time.

Key Features
✔ Robust Construction

316L stainless steel housing

IP68 protection (submersible)

5G vibration resistance

✔ Advanced Measurement

Dual 4-20mA or RS-485 Modbus output

Overpressure protection (2x full scale)

Optional LCD display for local readout

✔ Industrial Reliability

Works in -40°C to +85°C ambient temps

Compatible with oils, water, and mild corrosives

250,000+ hours MTBF

Typical Applications
• Hydraulic/pneumatic system monitoring
• Process automation control
• Energy management systems
• Industrial refrigeration units

Certifications & Options
Standard Compliance: CE, RoHS, REACH

Optional Certifications: ATEX/IECEx (for hazardous areas)

Variants Available:

-EX: Explosion-proof version

-HT: High-temperature (150°C) model

-F: Fluorocarbon seals for aggressive chemicals

Technical Highlights
→ G1/2" threaded connection for easy installation
→ NIST-traceable calibration available
→ 5-year warranty (standard conditions)

PH3 Gas Detector - Product Brief
Core Description:
The PH3 Gas Detector is an industrial-grade monitor designed for phosphine (PH₃) detection in hazardous environments. Featuring an electrochemical sensor with 0-20 ppm range, it delivers ±3% accuracy and rapid <30s response to protect workers in fumigation and chemical processing applications.

Key Features:
✔ Precision Detection

0.01 ppm resolution

Adjustable dual alarms (visual/audible)

Automatic self-calibration

✔ Rugged Design

ATEX/IECEx certified (Zone 1)

IP66 aluminum housing

-20°C to +50°C operation

✔ Smart Connectivity

4-20mA + RS-485 outputs

Optional LoRaWAN wireless

SIL 2 functional safety

Typical Applications:
• Grain storage fumigation
• Semiconductor manufacturing
• Chemical plant safety
• Pest control facilities

Certifications:
ATEX, IECEx, CE, RoHS

Model Options:

PH3-GD-W: Wireless version

PH3-GD-M: Multi-gas configurable

Technical Edge:
→ 2-year sensor lifespan
→ 95dB horn + LED strobe alarms
→ Plug-and-play sensor replacement

WFS-1001-H Flow Sensor - Product Brief
Core Description:
The WFS-1001-H is a high-performance digital flow sensor designed for precise liquid measurement in industrial applications. With a wide 0.5-50 L/min range and ±2% accuracy, it delivers reliable flow monitoring for water and compatible fluids.

Key Features:
✔ High Accuracy Measurement

0.1 L/min resolution

Bi-directional flow detection

Pulse (Hall Effect) or 4-20mA output

✔ Robust Industrial Design

Brass body with EPDM seals

IP65 protection rating

1.0 MPa pressure rating

✔ Easy Integration

G1/2" standard threaded ports

5-24V DC wide voltage input

<100ms fast response time

Typical Applications:
• HVAC system flow monitoring
• Industrial cooling circuits
• Water treatment plants
• Chemical dosing control

Technical Advantages:
→ Maintenance-free operation
→ Optional display model available
→ Compatible with all major PLCs

Certifications:
CE, RoHS, ISO 4064 Class 2 compliant

Version Options:
-A: Analog output version
-D: With digital display
