DIL M32C-XHI11-S
Technical Parameters
Parameter Specification Notes
Model DIL M32C-XHI11-S
Product Type Contactor with Integrated Electronic Module
Rated Operational Current (Ie) 32 A at AC-3, 400 V
Rated Operational Power (Pme) 15 kW (20 hp) at AC-3, 400 V
Rated Insulation Voltage (Ui) 690 V
Rated Operational Voltage (Ue) 230 V / 400 V / 690 V AC
Rated Control Supply Voltage (Us) 230 V AC Key specification for the "-S" variant
Motor Load (Utilization Category AC-3) 32 A at 400 V 15 kW
25 A at 690 V 18.5 kW
Resistive Load (Utilization Category AC-1) 32 A at 400 V
Mechanical Durability 10 million operations
Electrical Durability 1.5 million operations at AC-3, 32 A, 400 V
Integrated XHI11 Module Functions • Forbidden Simultaneity (Electronic Interlock): Prevents two interlocked contactors from closing simultaneously.
• Motor Locking Protection: Protects against jammed motors.
• Phase Reversal Protection: Detects and protects against incorrect phase sequence.
• Timer Functions: On-delay and Off-delay.
• Status Indication: Via diagnostic LEDs.
Terminals Cage Clamp For main and auxiliary circuits
Mounting Standard DIN Rail (35mm) or Panel Mount
Agency Approvals CE, cULus, RoHS, etc.
