Parameter Specification Product Model EACRO420SC Product Line Eaton EASY AC Soft Starter Rated Motor Power 20 HP (15 kW) @ 480V AC Rated Current 42 A (This is inferred from the model number "420", where 42 is the amperage) Supply Voltage 200-480 V AC, 50/60 Hz Control Method Voltage ramp control with built-in EnergySaver function (improves efficiency at partial load) Key Features

• Built-in Bypass Contactor: Reduces heat and energy consumption after start-up.
• Adjustable Start Voltage / Torque
• Adjustable Ramp Time
• Adjustable Stopping Mode (Coast, Soft stop)
• Integrated Overload Protection

Protection Functions

• Overload
• Phase Loss / Imbalance
• Overcurrent
• Heatsink Overtemperature

Control Connections Screw terminals for Start/Stop control and status relays. Mounting DIN Rail Mount (Standard 35 mm) Standards Compliance UL Listed, cULus, CE Marked

Parameter Specification Notes / Explanation Model Series DG4V Valve Size 03 CETOP 3, NFPA D01 Mounting Interface ISO 4401-03 NFPA D01, H7 Option Number of Ports 4 (P, T, A, B) Number of Positions 3 Actuation Type Solenoid Operated, Hydraulic Pilot Requires pilot pressure Solenoid Type Wet Armature DC Maximum Operating Pressure 350 bar (5,000 psi) Maximum Flow Capacity ~ 45 L/min (12 US gpm) Dependent on spool type and pressure drop Pilot Pressure Range 17 - 35 bar (250 - 500 psi) minimum Required for spool shifting Internal Pilot Supply From 'P' port Return Spring M Spring-centered to neutral position Manual Override U With manual override (standard) Seal Material Standard: Nitrile (Buna-N) Optional Viton available

The Rockwell Automation 800F-3MP22mm Enclosure PB is designed for industrial applications, offering robust protection for control systems. It is built to withstand harsh environments, ensuring reliable operation and long service life.
