The OMRON E5CN-QMTD-500 is a 1/16 DIN (48×48 mm) digital temperature controller from the E5CN series . This model features a voltage output (for driving an external SSR) as control output 1 and includes no auxiliary outputs (alarm outputs) .

Technical Data Parameter Specification Product Series NZM2 (Molded Case Circuit Breaker) Product Type Electronic Trip Molded Case Circuit Breaker Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 1000 V Rated Current (In) Determined by the X-Series Rating Plug. The specific current rating (e.g., 125A, 250A, 400A) is set by installing the appropriate plug (e.g., NZM1/2-XV200 for 200A). Poles 3 Poles (Typical configuration) Mounting Style Fixed Mounting Trip Unit Type Electronic Trip Unit (Communication-ready) Protection Functions LSIG • L - Long-time Delay (Overload) • S - Short-time Delay (Short-circuit) • I - Instantaneous (Short-circuit) • G - Ground-fault Rated Ultimate Breaking Capacity (Icu) High breaking capacity. The exact value depends on the specific frame size (e.g., N, H1, H2) and voltage rating. (e.g., can range from 50kA to 150kA at 415V AC). Communication Capability Ready for communication. Requires a separate communication adapter module (e.g., for Modbus, Profibus DP, Ethernet/IP) to be installed on the trip unit. Standards IEC 60947-1, IEC 60947-2 Electrical Durability 5,000 cycles (at rated current) Mechanical Durability 10,000 cycles

Parameter Specification Product Series Eaton DS7 / XStart Model Number DS7-340SX007N0-N Description Soft Starter, 34A, 15kW @ 400V Rated Supply Voltage 400V AC, 50/60 Hz Motor Power Rating 15 kW / 20 HP @ 400V Rated Current 34 A Current Range 5 - 34 A (Adjustable) Max. Current 150 A (for 1 second) Control Method Voltage Ramp, Current Limit Integrated Bypass Yes (Internal Bypass Contactor) Control Voltage 100-250V AC, 50/60 Hz (from factory, as denoted by 'SX') Control Connections Screw Terminals Start Time Adjustment 1 - 30 seconds (Adjustable) Torque Control Adjustable Initial Torque (Kickstart) and Torque Limit Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating, Jogging Protection Status Indication LED Indicators for Power, Run, Bypass, Fault Communication Optional communication modules (e.g., Profibus, DeviceNet) available Enclosure Rating IP00 (Open Type, must be installed in a control panel for protection) Standards & Certifications CE, UL, cUL, RoHS
