Technical Specifications Category Specification Model RB100 Type Self-Operated Backpressure Regulator Function To maintain a set upstream (inlet) pressure by relieving excess flow. Power Source Self-Operated (Uses energy from the process fluid) Body Style Globe Valve Body End Connections Flanged (ANSI Class 150 or 300 are common). Pressure Range Available in multiple, field-adjustable spring ranges for different setpoint requirements. Maximum Inlet Pressure Dependent on the body rating, but typically suitable for several hundred psig. Relief Capacity Determined by the orifice size, designed to handle the required relief flow. Temperature Range Standard with Buna-N diaphragm: -20°F to +180°F (-29°C to +82°C). Materials of Construction Body: Carbon Steel (WCB) or Cast Iron. Trim (Plug/Seat): Stainless Steel. Diaphragm: Buna-N (standard).

Key Parameters Product Type: Sectional Control Valve Stack (One Section) Brand: Eaton Valve Series: KHDG5V5 Spool Configuration: 3-position, Float Center Power Beyond: Yes (standard with this spool type) Nominal Flow Rate: 80 L/min Maximum Operating Pressure: Typically up to 350 bar (varies by model and seals) Work Port Relief Valve: Included, fixed setting (e.g., ~210 bar) Actuation: Single Solenoid, Electrical Coil Voltage: 120V AC, 50/60 Hz System Type: Open Center

Eaton Cutler-Hammer E2NM Molded Case Circuit Breaker is a heavy-duty mining service circuit breaker designed for high-voltage industrial power distribution systems. The E2NM series provides reliable overload and short-circuit protection for mining equipment, motor control centers, material handling systems, and industrial power networks. These breakers are available with thermal-magnetic, magnetic-only, or solid-state trip units and are engineered for operation up to 1000 VAC environments.
