Parameter Specification Product Series Eaton C25 (Combination Motor Starter) Model Number C25DNF240A Description Combination Motor Starter, 25A, 3-Pole, Non-Reversing, Fused, 240V AC Rated Current 25 A Maximum HP Rating 15 HP @ 240V AC / 25 HP @ 480V AC Poles 3 Rated Voltage 240V / 480V / 600V AC Short-Circuit Protection Fused (Fuse type and size specified by the "F" and the full model number) Overload Protection Included (Thermal or Electronic Overload Relay) Duty Non-Reversing (Standard Start/Stop) Control Voltage 240V AC (for the starter coil) Enclosure Type NEMA Type (e.g., NEMA 1, 12, 4, 4X) - depends on the specific ordered variant. Standards & Certifications UL 508, CSA C22.2 No. 14, IEC/EN 60947-4-1

Parameter Specification Product Series Eaton FWF Model Number FWF1016L Description Surge Protective Device (SPD), Type 2, 1P+N, 100kA, w/ Remote Signal Type Type 2 (For main distribution board protection) Rated Voltage 230V AC (Single-Phase) Max. Continuous Operating Voltage (Uc) 255V AC Nominal Discharge Current (In) 20 kA (8/20 µs, per pole) Max. Discharge Current (Imax) 100 kA (8/20 µs) Voltage Protection Level (Up) <1.5 kV (at In) Poles/Protected Circuits 1P + N Status Indication Visual (Green/Red indicator) Remote Signaling Yes (L) - 1 Change-over (SPDT) contact Mounting DIN Rail (35mm) Standards & Certifications IEC 61643-11, UL 1449 (4th Ed.), CE

Parameter Specification Product Series Eaton E2 (N Frame) Model Number E2NM3125T32WP09 Description Electronic Motor Management Relay, 125A, w/ Display & Comm Motor Current Setting Range (FLA) Up to 125 A Poles 3 (for 3-phase motor protection) Rated Operational Voltage (Ue) 690V AC Rated Supply Voltage (Us) 24-240V AC/DC Display Large Graphical LCD (T32) Communication Integrated (e.g., Modbus, PROFIBUS DP, as per "W" code) Protection Functions Thermal Overload (with Memory) Short-Circuit (Instantaneous) Phase Loss / Unbalance Jam / Stall Underload / Undercurrent Earth Fault (Restricted/Sensitive) Number of Starts / Time Between Starts RTD Inputs (for direct motor winding temperature monitoring) Control Functions Direct Start/Stop, Auto-restart, Fault Diagnostics Auxiliary Contacts Multiple programmable relays Mounting Panel-mounted or DIN Rail (with adapter) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton DIL H Model Number DIL H2600-XSM Description Power Contactor, 3-Pole, 260A, 230V AC Coil Rated Operational Current (Ie) 260 A (at AC-3, 400V) Rated Thermal Current (Ith) 260 A Poles 3 Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Utilization Category AC-3 (Squirrel-cage motors) Rated Power at AC-3 ~132 kW (at 400V) Coil Control Voltage 230V AC (as denoted by "-XSM" code) Auxiliary Contacts Typically includes at least 1 NO + 1 NC (as part of "-XSM" configuration) Mechanical Life Several million operations Electrical Life (AC-3) Hundreds of thousands of operations Mounting Screw mounting Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton Lightwatch Model Number ELJW4250 Description 4-Channel Relay Module, 16A/Channel, DALI Number of Outputs/Channels 4 Rated Load per Channel 16 A (Resistive, 250V AC) Total Rated Load 64 A Control Voltage 230V AC (Auxiliary Supply) Control Protocol DALI (Digital Addressable Lighting Interface) Communication Bus Lightwatch System Bus Mounting DIN Rail (35mm) within a distribution board Status Indication LED per channel for output status Standards & Certifications IEC 60669-1, CE, cULus

Parameter Specification Product Series Eaton Power Xpert DX Model Number PDG33F0600B2NN Description DIN Rail DC Power Supply, 600W, 24V DC Out Output Power 600 W Output Voltage 24 V DC Output Current 25 A Input Voltage Range 85 - 264 V AC (Wide Range, suitable for global use) Input Frequency 47 - 63 Hz Efficiency High (typically >94%) Power Factor (PFC) >0.98 Line Regulation <±0.5% Load Regulation <±0.5% Ripple & Noise <100mV peak-to-peak Protections Overload (110-150%), Overvoltage, Short-circuit, Over-temperature Operating Temperature -25°C to +70°C (with derating) Cooling Fan-cooled Mounting DIN Rail (35mm) Safety & EMC CE, cULus, RoHS, compliant with IEC/EN/UL 62368-1

Parameter Specification Product Type Solenoid Lock / Shunt Release (for Breaker) Model Number EGS3100FFG Description Solenoid Lock, 24-48V DC Rated Supply Voltage 24 - 48V DC Power Consumption Typically 10 - 20 W (inrush) Duty Cycle Continuous Function Prevents closing of the circuit breaker when energized Compatible With Specific models of Eaton molded case circuit breakers (MCCBs) and air circuit breakers (ACBs). Mounting Mounts directly onto the designated accessory slot of the compatible breaker. Connection Screw terminals Standards & Certifications As part of the breaker assembly, complies with relevant IEC/UL standards.

Parameter Specification Product Series Eaton E2 (Electronic Overload Relay) Model Number E2LEM3600W Description Electronic Overload Relay, 36-60A, Self-Protected Motor Current Setting Range (FLA) 36 - 60 A Poles 3 (for 3-phase motor protection) Rated Operational Voltage (Ue) 690V AC Rated Supply Voltage (Us) 24V AC/DC - 240V AC/DC (for the control circuit) Protection Functions Overload (Class 5, 10, 15, 20, 25, 30 adjustable) Phase Loss Phase Unbalance Jam / Stall Protection Undercurrent Earth Fault Protection (Optional, may require external CT) Self-Protected Feature Yes (Integral HBC fuse for short-circuit protection of the control unit) Auxiliary Contacts 2 NO + 2 NC (95-96 / 97-98 / 99-100 / 101-102) Terminals Screw Terminals Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Communication Optional communication modules (e.g., PROFIBUS, Modbus, DeviceNet) available Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton P5 Model Number P5-160/V/SVB Description Motor Protection Circuit Breaker, 160A Frame, Adjustable, 3-Pole Frame Size 160A Rated Operational Current (Iu) Adjustable within the frame range (e.g., 100A - 160A) Number of Poles 3 Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 790V AC Rated Short-circuit Breaking Capacity (Icu) High, e.g., 50 kA @ 400V AC (需查证具体目录) Overload Protection Setting (Ir) Adjustable (via a dial or switches) Short-Circuit Protection Setting (Im) Fixed or Adjustable (depending on model) Auxiliary Contacts Yes (as specified by "SVB" - typically includes signaling and control contacts) Mounting Fixed or Plug-in (depending on variant) Standards & Certifications IEC/EN 60947-2, IEC/EN 60947-4-1, UL 508, CE

Parameter Specification Product Series Eaton ELD6 (Electronic Accessory for D6 MCB) Model Number ELD6-63/4/C/03 Description Electronic Residual Current Release Module, for 4-Pole MCB, 63A, Curve C, 300mA Type A Compatible With Eaton D6 series, 4-pole, C-curve, up to 63A MCB Max. Rated Current of Assembly Up to 63 A Number of Poles 4 Poles (3 Phase + Neutral) Rated Residual Operating Current (IΔn) 300 mA Residual Current Type Type A (for alternating and pulsating direct currents) Technology Electronic (Requires auxiliary power from the monitored circuit to operate) Rated Voltage 400V AC (3P+N) Mounting Snaps onto the side of a compatible D6 MCB on a DIN Rail. Standards & Certifications IEC 61009-1, CE
