Technical Specifications
Electrical Characteristics:

Input Voltage: 85-264V AC (47-63Hz) or 120-370V DC

Output: 24V DC ±1% regulated

Current Rating: 36A (continuous)

Power Rating: 864W

Efficiency: 94% (typical at full load)

Inrush Current: <40A (at 230V AC)

Protection Features:

Overvoltage protection (auto-reset)

Short-circuit protection (hiccup mode)

Overload derating curve

Thermal shutdown with auto-recovery

Physical Specifications:

Dimensions: 215 × 125 × 60mm (W×H×D)

Weight: 1.8kg

Cooling: Forced air (integrated variable-speed fan)

Mounting: DIN rail (EN 60715) or panel mount

Environmental Ratings:

Operating Temperature: -25°C to +70°C (with derating above +60°C)

Relative Humidity: 5-95% non-condensing

Altitude: 5000m (with derating above 2000m)

Vibration Resistance: 3g (10-150Hz)

Key Features
Advanced Power Management

Active PFC (PF>0.98)

Parallel operation capability (up to 3 units)

Remote sense compensation

Monitoring & Control

LED status indicators (power, fault, load share)

Signal contact for power good/failure

Remote on/off control

Industrial Durability

Conformal coated PCB

Corrosion-resistant terminals

Reinforced housing (IK08 impact resistance)

Certifications & Compliance
Safety: UL 60950-1, EN 62368-1

EMC: EN 61000-6-2, EN 61000-6-4

Marine: DNV-GL, ABS

Railway: EN 50155 (optional)

RoHS & REACH Compliant
