Eaton FAZ-C10/2-RT – 10A dual-pole residual current circuit breaker (RCCB), Type C tripping curve, 30mA sensitivity. DIN rail mount, 230V AC rating. Provides earth leakage protection for residential/commercial circuits. Complies with IEC 61008-1.

Key Specifications
Electrical Parameters:

Voltage Rating: 230V AC (50/60Hz)

Max Continuous Voltage (Uc): 275V AC

Nominal Discharge Current (In): 10kA (8/20μs)

Impulse Current (Iimp): 25kA (10/350μs)

Voltage Protection Level (Up): ≤1.5kV

Protection Features:

Combined Protection: Meets Type 1+2 requirements (IEC 61643-11)

Thermal Disconnector: Automatic fail-safe mechanism

Visual Status Indicator: Green/Red window

Remote Signaling: Optional contact available

Mechanical Specifications:

Mounting: DIN rail (35mm)

Connection: 10mm² max wire size

Housing Material: Flame-retardant thermoplastic (UL94 V-0)

Dimensions: 90 x 70 x 65mm (WxHxD)

Weight: 0.35kg

Certifications & Standards
IEC 61643-11 (Type 1+2)

EN 61643-11 compliant

CE Marked

UL 1449 4th Edition Listed

RoHS & REACH compliant
