Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered, tandem center Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At rated pressure Response Time < 30 ms Solenoid actuation Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Coil Resistance 22 Ω ±10% Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Recommended Viscosity 10-100 mm²/s

Designed for industrial automation and drive systems, this SIEMENS motion control module is ideal for precision control tasks in a variety of complex environments. It supports multiple control strategies that significantly improve productivity and equipment reliability.

The Foxboro FBM241C P0914WM is an advanced channel-isolated 8 input module designed for enhanced process control in demanding industrial environments. It offers unparalleled reliability and precision, making it ideal for applications requiring high accuracy and robustness.
