800-22232
Product Description:
The Honeywell 800-22232 is a rugged, adjustable pressure switch designed for HVAC, industrial machinery, and fluid control systems. Its snap-action SPDT switch provides reliable on/off control for pumps, compressors, and alarms.
Key Features:
✔ High-Current Switching – Directly controls loads up to 15A
✔ Field-Adjustable – Set point customizable via hex key
✔ Wide Pressure Range – Configurable for low-to-medium pressure applications
✔ NEMA 4X Equivalent – IP65 rating for harsh environments
Typical Applications:
HVAC: Air compressor control, refrigerant line monitoring
Industrial: Hydraulic/pneumatic system protection
Water Treatment: Pump cycling, tank level cutoff
Automotive: Brake system pressure sensing
EIS-40/1
Key Parameters
Category Description / Value
Product Line Eaton EIS (Signal Towers)
Series EIS-40
Type Single-level Module
Lens Diameter 40 mm
Mounting Designed for modular stacking with other EIS-40 units and accessories.
Compatible Lamps/LEDs Uses separate bulb or LED cartridges (e.g., standard incandescent, long-life LED modules) which are inserted into the unit.
Lens Colors Available in various colors (e.g., Red, Yellow, Green, Blue, White) depending on the ordered variant.
Voltage Depends on the installed lamp or LED cartridge (e.g., 24V, 48V, 110V, 230V AC/DC).
Connection Typically screw terminals.
